20 T heavy duty platform cart With Mecanum Wheel Remote Control



RWP is a heavy duty platform cart offering battery-operated multidirectional driving with self-loading operations – real game changer for a variety of industries! Designed and manufactured in Italy RWP has lots of benefit and special features:

INCREASED PRODUCTIVITY

RWP minimizes cranes usage, thanks to the lifting deck which allows to these multidirectional battery powered trolleys to lift and move heavy load where needed.

SUITABLE FOR ALL TYPES OF LOAD

RWP is a motorized cart perfect for handling both small and extremely heavy duty loads thanks to its modular design and its high payloads: over 200 ton for each trolley.

SUITABLE FOR ALL TYPES OF SPACES

RWP heavy duty platform cart is extremely compact and thanks to all the different types of electric steering (90°, carousel, diagonal, compass) it can move even in very narrow spaces.

SUITABLE FOR ALL TYPES OF ENVIRONMENT

RWP is a perfect example of electric platform cart extremely silent, completely non-polluting and requires almost no maintenance. Its steering and traction are entirely electric (AC brushless engines) and it is battery-powered. OMNI is also designed for use in hazardous areas.



20 T heavy duty platform cart With Mecanum Wheel Remote Control



SUITABLE FOR ALL TYPES OF FLOORING

Hydraulic suspensions, mechanical oscillation of axles and various available types of wheels allow OMNI to work even outdoors, ensuring an even load distribution on uneven floors.

FULLY CUSTOMIZABLE

RWP heavy duty platform cart can be customized according to all customer needs (dimensions, payload, battery life, superstructures and many others).

FULL SUPPORT

RWP can be equipped with a remote assistance board ensuring swift after-sales service directly from the production plant.



Technical parameters for electric transfer carts
1 rated load(t) 5 10 15 20 30 40 50 150
2 impacted rated load(t) 7.5 15 22.5 30 45 60 75 225
3 structure of frame steel plates welded, beam structure
4 max. wheel load(t) 2.8 4.3 4.8 5.6 7.7 10 12 27
5 ground requirement cement floor steel plate ground
6 table size(mm) 3000×2000 3600×2000 4000×2200 4500×2200 5000×2200 5500×2300

6000×

2300

10000×

3000

7 height of the whole cart(mm) 450 530 600 600 650 700 700 1200
8 ground clearance(mm) 50 75
9 wheels base(mm) 1500 1700 1800 2000
10 axles distance(mm) 2500 3100 3400 3900 4300 4800 5200 10000
11 turning radius(mm) 2501 3101 3401 3901 4301 4801 5201 10001
12 turning type turning while driving with no stop
13 control method for turning control button
14 turning structure mechanical
15 motor power(Kw) 3.5 5 6 7 10 12 15 15
16 wheel diameter(mm) Ф300 x 4 Ф350 x 4 Ф400 x 4 Ф400 x 6 Ф500 x 6 Ф600 x 8
21 battery model D-250 x 24 D-33 x 24 D-400 x 24 D-440 x 24 D-250 x 36 D-330 x 36 D-440 x 36 D-600 x 36
22 battery maintenance free of maintenance
23 charger's installation installed on cart split-type
24 charger function automatic charging
25 radar control 3-0.3m, automatic stop for obstacles
26 warning equipment sound and light
27 other functions turning light, night light and power display



" }
