Extrusion Blow Molding Machine HDPE PP Bottle Making Machines 5L
Car Motor Oil Lubricant High Speed Plastic Blow Machine
DAWSON MACHINERY& MOULD GROUP
***EXTRUSION BLOW MOLDING MACHINE EXPERT***
Our customers are all around the world.
Vietnam, Australia, Indonesia, Malaysia, Thailand, Sri Lanka,
Kazakhstan, Russia, UAE, Saudi Arabia, Malta, Romania, Italy,
India, Syria, Ethiopia, Egypt, Sudan, Tunisia, Algeria, Kenya,
Nigeria, South Africa, Zimbabwe, Mexico, Guatemala, Ecuador,
Colombia, Venezuela, Peru....
Product Description
Automatic Extrusion Blow Molding Machine DSB70II
u Product: 0~5 L Bottles
u Power supply: 380/220v 50/60 Hz Tri-phase
u Die head number: Single / Double
u Suitable raw material: PE, PP, PVC, PS, PETG
u Output capacity: 180~200 pcs/h (5L) / with single head
400~450 pcs/h (1L) / with double head
Product Parameters
| SPECIFICATIONS | UNITS | DSB70II SERIERS |
| Max container capacity | L | 5 |
| Number of die heads | Set | 1 |
| Dry cycle time | Second | 5 |
| Machine dimension (L*W*H) | M | 3.3*2.3*2.6 |
| Total weight | Ton | 5.5 |
| CLAMPING UNIT |
| Clamping force | KN | 68 |
| Platen opening stroke | mm | 200-500 |
| Platen size | mm | 360*470 |
| Max mould size (W*H) | mm | 390*470 |
| Mould thickness | mm | 210-300 |
| Platen moving distance | Mm | 440 |
| POWER |
| Extrusion motor power | KW | 22 |
| Oil pump motor power | KW | 5.5 |
| Extrusion heating power | KW | 12 |
| Head heating power | KW | 5.7 |
| Cooling Fan power | KW | 0.26 |
| Total power | KW | 45.46 |
| Average power consumption | KW | 23.5 |
| EXTRDER UNIT |
| Screw diameter | mm | 70 |
| Screw L/D ratio | L/D | 24 |
| Plasticizing capacity | Kg/hour | 90 |
| Number of heating zone | Zone | 3 |
| Extruder heating power | KW | 14.2 |
| Extruder driving power | KW | 22 |
| Cooling Fan No | | 2 |
| Fan power | KW | 0.26 |
| DIE HEAD |
| Head type | Continuous extrusion head |
| Head No | 1 | 2 | 3 | 4 |
| Central distance / mm | - | 160 | 110 | 85 |
| Max die diameter / mm | 135 | 80 | 50 | 30 |
High quality mould
In the process of plastic blow molding, the mold is a very
important part. A good blow mould can make the product production
more smoothly, and a good blowing mold can also make the finished
product more flexible and beautiful.
We have our own mold production workshop, using high configuration
equipment and mold engineers with 16 years of technical experience
to customize blow molding mold for you.
- We use the best stainless steel S136H or Aluminium alloy 7075# as
mould main material- Necking plate use JAPAN DC53 Heat
treatment to HRC62
- Double neck design available to change in future as a spare part
necking
- All mould can be made auto-deflashing or manual deflashing as per
customer requests
- Perfect mould cooling design to ensure the best moulding
preformace
- Available to provide 2D & 3D product drawing for customers
- Available to send samples to customer for approval the product
quality
- We had already made moulds for
TOTAL,SHELL,GULF,BMW,YAMAHA,MOBIL,TOYOTA,MENGNIU,
HYUNDAI,MENTHOLATUM,UNILEVER,LEE KUM KEE...
Company Profile
Our customers are all around the world.
Vietnam, Australia, Indonesia, Malaysia, Thailand, Sri Lanka,
Kazakhstan, Russia, UAE, Saudi Arabia, Malta, Romania, Italy,
India, Syria, Ethiopia, Egypt, Sudan, Tunisia, Algeria, Kenya, Nigeria,
South Africa, Zimbabwe, Mexico, Guatemala, Ecuador, Colombia, Venezuela, Peru....
We have our own service team in
Saudi Arabia, Colombia, Panama, South Africa ...
DAWSON MACHINE & MOULD GROUP
located in Zhangjiagang city, have more than 18 years' experience
in the field of plastic machinery,
blow molding machine, injection molding machine, PET blow molding machine, injection blow
molding machine, during the past 18 years, we always force our energy into new areas of plastic machinery, plastic packaging
machinery, to update the technology, to learn advanced experience,
to confirm new theory and new design, we are forming a unique
competitive advantage of our owns.
The machines from our company carry good quality and effective
after-sales service, upon the market,
customers from more than 45 countries, we provide complete solution for your plastic industry
business, as well as all sorts of technical support & after-sale services!
DAWSON will be your reliable friend in China, and we will always do
our best to give you max support!After Sales Service
FAQ
Q: Can we visit your factory?
Sure. We located in Zhangjiagang city which is very near Shanghai.
For overseas customers, you can fly to Shanghai Pudong
International Airport. We can
pick you up in the Airport. (or Hongqiao International Airport. )
We also provide visit online by video.
Q: How can we get the exact price of plastic machine?
Contact us with the products size, shape, annual quantity and photo
if possible. We can recommend our machine models with
quotation.
Q: Do you provide any spare parts with machine?
Yes, we offer all necessary spare parts before shipment.(contact us
for packing list )
Q: How about your after-sale service ?
We offer manual instruction and engineer training before
loading,after shipment we provide 24 HRS online support, video
technical
support or field installation assist.
Q: What is the lead time?
For customized machine, it takes about 45-50 days after deposit. For stock machine, fast shipment. ( The actual
production cycle will vary according to the degree of
customization.)
Q: What is the warranty period for your machine ?
12 months warranty for components and technical support .
Q: Do you provide custom machines?
Most of our machines are customized. Our goal is efficiency and
stable performance. We design the machines according to customers
products to meet customer' needs.
Q: How can we install the machine when it arrives?
We can send experienced technicians to customer's country for
guiding the installation and commission the machine, also train the
customer's employees.
Q: What's DAWSON's advantage?
DAWSON provide customers with turnkey projects. Including plant
design, plastic machine and mold installation, debugging, also we
can source the auxiliary equipments for customers. We can ship the
full set of machines after testing in our factory. It will save
a lot of cost and time.
