CFPT1214 Self Propelled Scissor Lifts Hydraulic Drive Safe Working
Platform
General Introduction of this mini scissor lift platform
1. Load capacity: 320kg
2. Lifting height: 13.8m
3. Applications: aerial installation, maintenance, clean at the
construction sites, workshops, warehouse, hotel, airport, wharf,
gas station and stadium etc.
4. Custom-made according to the requirement
5. The worker can control the scissor lift on the platform when
raised by handle .
6. The worker can also control the lift on the floor by handle
control
Specification
| Parameter | Unit | CFPT1214 |
| Rated Load Capacity | Kg | 320 |
| Extended platform load | Kg | 113 |
| Max. working height | m | 13.8 |
| Max. platform height | m | 11.8 |
| Length (L) | mm | 2480 |
| Width (W) | mm | 1190 |
| Height(guardrail unfolded) | mm | 2570 |
| Height(guardrail folded) | mm | 2030 |
| Platform size | mm | 2270x1120 |
| Platform extended | mm | 900 |
| Ground clearance (Lower) | mm | 100 |
| Ground clearance (Raised) | mm | 19 |
| Wheel base | mm | 1895 |
Min. Turning radius (inner wheels) | mm | 0 |
Min. Turning radius (outer wheels) | mm | 2200 |
| Lifting motor/Drive motor | V/Kw | 24/4.5 |
| Travel speed(Lower) | Km/h | 3.5 |
| Travel speed(Raised) | Km/h | 0.8 |
| Lifting/Descend speed | sec | 60/50 |
| Battery | V/Ah | 4x12/30 |
| Charger | V/A | 24/25 |
| Grade ability | % | 25 |
| Max. working inclination | . | 1.5/ 3 |
| Tyre size | mm | Φ381x127 |
| Overall weight | Kg | 2980 |
Standard equipment
Proportional controls
Self-lock gate on platform
Extension Platform
Drivable at full height
Non marking tyre
2WD
Automatic brakes system
Emergency lowering system
Emergency stop button
Tubing explosion-proof system
Onboard diagnostic system
Tilt sensor with alarm
All Motion Alarm
Horn
Hour meter
Safety brackets
Forklift pockets
Charger protection
Flashing beacon
Folding guardrails
Automatic pothole protection
Product Description
As the ideal model for flexible operation in narrow space,
hydraulic electric slab scissor lifts feature nice appearances,
compact structures, stability, reliability, strong power
performance and field adaptability, flexible operation, excellent
quality and safety.
Scissor Lifts cover 8m to 16m work height, hydraulic powered,
electric motor drive, which have long run time, and high
productivity. The energy•efficient direct electric drive boosts
your productivity with industry•leading duty cycles. It is safe and
reliable,so it is the optimal product for aerial lifting operation,
such as aerial cleaning, repairing, and maintenance.
Self-propelled Scissor Lifts are energy-saving and
environmentally-friendly with less noise and no emission. With
proportional controls for lift and drive functions, the CFMG slab
scissor lift boasts the versatility to work in indoor and outdoor
construction, maintenance and installation applications with firm,
level surfaces.
Service
1. All the machines will be full tested before shipment
2. The total machine guarantee is 12 moths
3. 24 Hours technical support, email, telephone or video online
4. User-friendly english manual for machine using and maintaining
5. Sereral sets wearing parts will be free for you
