9600 DPI Double Head Foldable Vertical Wall Inkjet Printer Metal
Art Tile Wood Board Paper Wall Printing Machine
(Model:PE-S80)
★ Product Introduction:
In order to meet the different needs of different customers,
Perfect Laser develops new generation industrial intelligent wall
printing machine PE-S80.
The design of industrial 3d vertical wall inkjet printer nozzle is different from that of conventional wall printing machine. It has a higher printing speed, can satisfy large-scale work for
a long time, and is more stable in performance. And the standard
track of the wall printing machine can be up to 6M, more widely
used.
★ Product Features:
1. Aluminum-magnesium alloy wall printing machine body, which has higher strength, high structural accuracy, light
weight and durability.
2. The actual printing size of the wall inkjet printer : height 2000mm, the track standard width is 6m and the 3d
vertical wall printer can be extended if need.
3. High-precision brushless servo motor control system, vector
positioning, no strip grating, motor brushless, (avoids cleaning,
maintenance, garbled graphics after wear, need to be replaced
regularly, etc.) to achieve higher painting accuracy, faster
painting speed, and maintenance-free of the inkjet printer for wall
mural.
4. The wall inkjet printer using high-definition piezoelectric ink
jet technology, high precision, high speed, and durability. Special
designed nozzle for industry usage.
5. Adopt VSDT variable ink drop technology, supporting a new
program algorithm, the smallest drop of 3d vertical wall inkjet
printer is 3.5PL, the largest 47PL. The combination of advanced ink
drop control method with high fault tolerance feathering technology
ensures the output quality is more perfect and the 3d vertical wall
printer can adapt to the painting of more special materials, such
as: interior and exterior wall putty wall surface, latex paint wall
surface, big white, imitation porcelain wall Surfaces, tiles,
glass, rice paper, canvas, wall clothing, color coating glaze,
shell powder, color grain paint and other walls.
6. The sprinkler data signal of the wall inkjet printer adopts
optical fiber integrated transmission (its advantages are: faster
speed, strong anti-interference ability, high reliability, more
stable transmission data).
7. The output module was upgraded and the output of industrial
models increased by 1 time.
8.The special ink for wall printing machine adopts imported color paste without heating. It can work normally
in the environment of minus 10°C to 60°C above zero, without
freezing and continuous ink. Bright colors, strong
three-dimensional effect; no fading, no peeling, scrub resistance,
green environmental protection certification, national standard
testing qualified (GB18582-2001, GBT9756-2001).
9.The data signal of the nozzle is transmitted by optical fiber
integration (its advantages are: faster speed, strong
anti-interference ability, high reliability. The transmission data
is more stable).
★ Application:
The wall printing machine is widely applied in interior and exterior wall putty walls, latex
paint walls, white, imitation porcelain walls, tiles, glass, rice
paper, canvas, wall clothing, color coating glaze, shell powder,
color grain paint and other walls.
★ Technical Parameters:
| Model | PE-S80 wall printing machine |
| Printing Head | Japan imported industrial grade printing head |
| 2 pcs |
| Painting Speed | 64㎡/h |
| Main-board Configuration | 8-core CPU, 4GB DDR memory |
| UPS Battery Life | About 12 hours |
| Pad Size | 11.6 inch |
| Rail Size(L×H) | 4500mm×2500mm |
| Host Size (L×W×H) | 400mm×320mm×2640mm |
| Sensor | Double |
| X Axis Effective Stroke | 2000mm |
| Y Axis Effective Stroke | Unlimited |
| Z Axis Effective Stroke | 150mm |
| Z Axis Guide | 170mm |
| Z Axis Automatic | Have |
| Ink Consumption Per Square | 6-10ML |
| Nozzle Protective Device | Have |
| Spirit Level | Have |
| Automatic White Jump | Have |
| Nozzle Cleaning | One Key Automatic |
| Painting Accuracy | 9600DPI |
| Painting Direction | Vertical |
| Painted Mode | two-way |
| Ink Tank Capacity | 400ML=100ML×4 |
| Spray Distance | 0.5-2.0cm |
| Ink Supply Method | Automatic ink supply under negative pressure |
| Data Transmission Method | USB2.0/3.0 |
| Certification | CE/GB18582-2001/GBT9756-2001 |
| Power Supply | AC110V (90-132V)/AC220V (180-264V) , 47-63HZ |
| Power Consumption | No load:20W, Generally:75W, MAX: 250W |
| Noise | Standby <20dBA, Drawing <50dBA |
| Working Temperature | -10°C-60°C (14°F-140°F) 10%-80% relative humidity, non-condensing |
| Storage Temperature | -30°C-60°C (-22°F-140°F) 10%-80% relative humidity, non-condensing |
| Language | Chinese and English (Customized) |
| Total Body Weight | 32 kgs |
| Total Track Weight | 38 kgs |
| Training | VCD training, Engineer overseas training is available (charged
additionally) |
| Guarantee | 12 months |
