W Section Powder Coating Green 8ft Steel Security Palisade Fencing
Steel security palisade fencing introduction
It is a high spec security fencing it is designed to provide a
formidable barrier against intrusion and theft.
It is manufactured using hot-formed and cold-rolled substantial
steel sections.
It is a cost-effective way to provide a high level of security to
the boundary line of any property.
Steel security palisade fencing size
| Height |
Post Dimensions |
Rail Dimensions |
Support Legs |
Corrugated Steel Palisades |
1.2m |
102x44 or 100x55 |
40x40x6mm |
1 |
W - 2.0mm or D - 3.0mm |
1.5m |
102x44 or 100x55 |
40x40x6mm |
1 |
W - 2.0mm or D - 3.0mm |
1.8m |
102x44 or 100x55 |
40x40x6mm |
1 |
W - 2.0mm or D - 3.0mm |
2.0m |
102x44 or 100x55 |
45x45x6mm |
1 |
W - 2.0mm or D - 3.0mm |
2.1m |
102x44 or 100x55 |
45x45x6mm |
1 |
W - 2.0mm or D - 3.0mm |
2.4m |
102x44 or 100x55 |
45x45x6mm |
1 |
W - 2.0mm or D - 3.0mm |
2.7m |
102x44 or 100x55 |
50x50x6mm |
1 |
W - 2.0mm or D - 3.0mm |
3.0m |
127x76 |
50x50x6mm |
2 |
W - 2.5mm or D - 3.5mm |
3.6m |
127x76 |
50x50x6mm |
2 |
W - 2.5mm or D - 3.5mm |
Steel security palisade fencing drawing
Steel security palisade fencing details
Post centers
2.75m
Heights
1.2m
1.5m
1.8m
2.0m
2.1m
2.4m
3.0m
Paling tops
Single pointed
Triple pointed
Square
Round and notched
Rounded
Pale thickness
‘W’ profile 2.0mm – commercial specification
‘W’ profile 2.5mm – general purpose to BS: EN: 1722 Pt 12
‘W’ profile 3.0mm – security purpose to BS: EN: 1722 Pt 12
‘D’ profile 3.0mm – general purpose to BS: EN: 1722 Pt 12
‘D’ profile 3.5mm – security purpose
‘D’ profile 4.0mm – security purpose to BS: EN: 1722 Pt 12
Horizontal cross rails
Three standard sizes to suit height and site requirements.
45x45mm for 1.2, 1.5 and 1.8m heights
50x50mm for 2.0, 2.1 and 2.4m heights
65x50mm for 3.0m
Steel security palisade fencing features
Anti-climb: without feet-holds and with sharp heads, the fence made itself
impossible to climb.
Versatility: The spacing could be adjusted to satisfy your various demands,
separate pales made it possible for uneven terrains.
Rigidity structure: The large and heavy pales are more rigid.
Smooth surface: Power coated surface made the fence more delightful and
attractive.
Forbidding appearance: The sharp heads alert passerby deter the entrance of intruders.
Simple to install, ideal for secondary operations: The pales are bolted together, which made it easy to install and
could be taken into parts for secondary use.
Durable: The panel sheet is galvanized uniformly and PVC coated, which
ensures a long service life.
Steel security palisade fencing usage
Common uses include railway and track protection, schools, colleges
and universities, research laboratories, motorways and highways
protection, utility companies protection and around industrial
sites.
