317 | 317L Thin Stainless Steel Strip Coil Roll Annealed ,2B
Hairline Finished 1/8 Hard Tempered
317 | 317L Thin Stainless Steel Strip Coil Roll Annealed ,2B
Hairline Finished 1/8 Hard Tempered overview
Type 317 is an austenitic chromium-nickel stainless steel with
excellent corrosion resistance; Its high Molybdenum content
enhances the grade's superior pitting resistance. It is the most
corrosion resistant of the 300 Series alloys and possesses the
highest tensile and creep strength properties at elevated
temperatures.
PRODUCT FORMS:
Sheet, plate , Strip, pipe ,tube ,bar ,profiles
Equivalent Materials DIN 1.4449 AFNOR Z6CND17-12-04 SAE 317 JIS SUS317 JIS SUS317TP JIS SUS317TB JIS SUS317TPY JIS SUSF317 EN X3CrNiMo18-12-3 EN 1.4449 UNS S31700 ASTM TP317 ASTM 317 ASTM F317 ASTM S31700 ASTM MT317
317 | 317L Thin Stainless Steel Strip Coil Roll Annealed ,2B
Hairline Finished 1/8 Hard Tempered Products Specification and Dimension Ranges
321 Stainless Steel Specifications:
ASTM A240 for annealed condition ASTM A666 for tempered material
Hot Rolled Strip Available Size
Width: 16.0~609.6 mm Thickness: 2.5~10.0 mm Available Steel Grade:
Cold Rolled Strip Available Size
Width: 4.0~609.6 mm Thickness: 0.1~3.0 mm
Surface Finish:
2B, 2D, BA, No.3, No.4, No.5, SB, HL, etc
Surface finish
Characteristics and application
NO.2B
The surface brightness and flatness of no2B is better than no2D.
then through a special
surface treatment to improve its mechanical properties,No2B could
nearly satisfy compreh
ensive uses.
NO.1
The surface is finished by heat treatment and pickling or processes
corresponding thereto
after hot rolling.
NO.4
Polished with abrasive belt of grit #150-#180,have better
brightness with discontinuous
coarse stria,but thinner than No3, are used as bathtub buildings
inner and external
ornaments electrical appliances kitchen utensils and food
processing equipment etc.
HL
Polished with abrasive belt of grit #150#320 on the NO.4 finish and
has continuous
streaks,mainly used as buildingsornaments elevators,door of
building,frontal plate etc.
BA
Cold rolled, bright annealed and skin-passed, the product have
excellent brightness
and good reflexivity like mirror,kitchen apparatus,ornament etc.
8K
The product have excellent brightness and prefer reflexivity can to
be the mirror.
Condition :
ANNEALED CONDITION
Ultimate Tensile Strength: 95 KSI min (655 MPA min) Yield Strength
(0.2% Offset): 38 KSI min (260 MPA min) Elongation: 40%min
Hardness: B95 max
TEMPERED 1/16 HARD
Ultimate Tensile Strength: 95 KSI min (655 MPA min) Yield Strength
(0.2% Offset): 45 KSI min (310 MPA min) Elongation: 40% min
Tempered 1/8 Hard Ultimate Tensile Strength: 100 KSI min (690 MPA
min) Yield Strength (0.2% Offset): 55 KSI min (380 MPA min)
Elongation: 45% min
TEMPERED 1/4 HARD
Ultimate Tensile Strength: 125 KSI min (860 MPA min) Yield Strength
(0.2% Offset): 75 KSI min (515 MPA min) Elongation: 25% min
317 | 317L Thin Stainless Steel Strip Coil Roll Annealed ,2B
Hairline Finished 1/8 Hard Tempered Application
Automotive and architectural trim, springs, kitchen and restaurant
equipment and utensils, dairy and food processing equipment
317 | 317L Thin Stainless Steel Strip Coil Roll Annealed ,2B
Hairline Finished 1/8 Hard Tempered Technical datasheet
CHEMISTRY TYPICAL
Carbon: 0.08 max Manganese: 2.00 max Silicon: 0.75 max Chromium: 18.00-20.00 Nickel: 11.00-15.00 Molybdenum: 3.00-4.00 Phosphorus: 0.045 max Sulfur: 0.030 max Nitrogen: 0.10 max
MECHANICAL PROPERTIES AT ROOM TEMPERATURE PROPERTIES: ANNEALED
TYPICAL
Ultimate Tensile Strength: 75 KSI min (517 MPa min) Yield Strength:
30 KSI min (205 MPa min) Elongation: 35% min Hardness: Rb 95 max
PROPERTIES TEMPERED
Type 317 can be cold worked to various tempers. Contact US for
additional information.
ADDITIONAL PROPERTIES
FINISHES
# 1 - Hot rolled annealed and descaled. It is available in strip,
foil and ribbon. It is used for applications where a smooth
decorative finish is not required. # 2D - Dull finish produced by cold rolling, annealing and
descaling. Used for deep drawn parts and those parts that need to
retain lubricants in the forming process. # 2B - Smooth finish
produced by cold rolling, annealing and descaling. A light cold
rolling pass is added after anneal with polished rolls giving it a
brighter finish than 2D. #BA- Bright annealed cold rolled and bright annealed #CBA- Course bright annealed cold rolled matte finish and bright
anneal #2 - Cold Rolled # 2BA- Smooth finish produced by cold rolling and
bright annealing. A light pass using highly polished rolls produces
a glossy finish. A 2BA finish may be used for lightly formed
applications where a glossy finish is desired in the formed part.
Polished - Various grit finish for specific polish finished
requirements.
COLD FORMING
Type 317 can be readily formed and drawn.
HEAT TREATMENT
Type 317 is non hardenable by heat treatment.
317 | 317L Thin Stainless Steel Strip Coil Roll Annealed ,2B
Hairline Finished 1/8 Hard Tempered Products display and Package Details
FAQ
Q: Would you provide samples For free?
A: Yes . with on stock specification We provide samples For Free .
Freight charge collect
Q:What information should i provide to source for the right
products ?
A: Material grade, width, thickness, coating and Purchase quantity
, Expected lead time ,etc
Q:What are the shipping ports?
A:Under normal circumstances, we ship from Shanghai, Tianjin,
Qingdao, Ningbo ports, you
canchoose other ports according to your needs.
Q:About product prices?
A:Prices vary from period to period due to cyclical changes in the
price of raw materials.
Q:How long does your delivery time take?
A:In general, our delivery time is within 5-45 days, and may be
delayed if the demand is extremely
large or special circumstances occur.
Q:Can I visit your location?
A:Of course, we welcome customers from all over the world to visit
our factory. However, some
of theplants are not open to the public.
Q:Does the product have quality inspection before loading?
A:Of course, all our products are strictly tested for quality
before packaging, and unqualified
products will be destroyed.
Q:How to pack the products?
A:The inner layer has a waterproof paper outer layer with iron
packaging and is fixed with a fumigation
wooden pallet. It can effectively protect products from corrosion
during ocean transportation.
Q:What is your working time?
A:In general, our online service time is Beijing time: 8:00-22:00,
after 22:00,
we will reply to your inquiry during the next working day.
317 | 317L Thin Stainless Steel Strip Coil Roll Annealed ,2B
Hairline Finished 1/8 Hard Tempered Equivalent
SAE 302 JIS SUS302 ASTM MT302 ASTM 302 UNS S30200 DIN 1.4324 AISI
301 SAE 301 JIS SUS301J1 EN FE-PA 18 EN 1.4324 ASTM 301 302 ASTM
MT301
