    980nmm Singlemode Wideband Directional Coupler Bidirectional

    Ask Lasest Price
    Brand Name : GaPho
    Model Number : Fiber Optical Coupler
    Price : Negotiable
    Payment Terms : T/T
    Supply Ability : 20000/week
    Delivery Time : 7-10 day
    • Product Details
    • Company Profile

    980nmm Singlemode Wideband Directional Coupler Bidirectional

    Fiber Optical Coupler Singlemode Wideband Coupler (Directional And Bidirectional)

    Features

     Wide Passband

     Low Insertion Los

     Low PDL

     High Reliability


    Applications

     Optical Communication System

     Local Area Networks (LAN)

     CATV

     Fiber Sensor Systems

     Optical Test System

    Specifications
    ParametersGrade PGrade A
    Port1x2 or 2x2
    Operating Wavelength (nm)980, 1310, 1550, C band, L band, or C+L Band
    Bandwidth (nm)980 (1310, or 1550) ± 40, 1528~1565 (C), 1570~1605 (L)
    Insertion Loss (dB)50/50≤3.4≤3.6
    40/60≤4.4/2.6≤4.7/2.8
    30/70≤5.7/1.9≤6.0/2.0
    20/80≤7.6/1.25≤8.0/1.3
    10/90≤11.0/0.65≤11.5/0.8
    5/95≤14.2/0.4≤14.8/0.5
    2/98≤18.5/0.25≤19.0/0.35
    1/99≤21.5/0.2≤22.0/0.3
    PDL (dB)≤0.1≤0.15
    Directivity (dB)≥55
    Fiber TypeSMF-28e; Clear Curve XB; Others on Request
    Working Temperature (°C)-40 ~ +85
    Package (mm)250um Bare Fiber: Steel Tube, 3 X 54 / 45
    0.9 mm Loose Tube: Steel Tube, 3 X 54
    2 mm or 3 mm Cable: ABS Box, 90 X 20 X 10

    Notes: All the data are tested without connectors. Insertion loss of one pair of connector is less than 0.3 dB. Other specifications can be made on customer request.

    Order Information
    Wideband CouplerPortSplit RatioGradeWavelengthFiber TypePigtailPackageFiber LengthConnector
    1 × 2
    2 × 2
    50/50
    40/60
    30/70
    20/80
    10/90
    5/95
    2/98
    1/99
    P
    A
    980
    1310
    1550
    1310/1550
    1528~1565
    1570~1605
    C+L Band
    Custom...
    SMF-28e
    Curve® XB
    Custom …
    250 μm
    0.9mm
    2mm
    3mm
    Φ3 × 54
    90×20×10
    Custom …
    0.50 ± 0.05 m
    1.00 ± 0.1 m
    Custom …
    None
    LC/UPC
    LC/APC
    SC/UPC
    SC/APC
    FC/UPC
    FC/APC
    Custom …
