| Parameter range |
| 1, Flow-rate: 1.0~1200.0 ml/h, 0.1ml/h step; |
| 2, Time: 1s~99h59m59s, 1s step; |
| 3, Drop-rate: 1~333 d/min, 1 d/min step; |
| 4, Dose: 0.1~999.9 mg, 0.1mg step; |
| 5, mg/kg/h: 0.001~999.999 mg/kg/h, 0.001 mg/kg/h step; |
| 6, Body-weight: 1~300 kg, 1kg step; |
| 7, KVO rate: 1.0~5.0 ml/h, 0.1 ml/h step; |
| 8, Bolus rate: 50.0~800.0 ml/h, 0.1 ml/h step; |
| 9, Bolus volume: 0.1~99.9 ml/h, 0.1ml step |
| Precision |
| Better than ±5% (using a calibrated or a special IV-set) |
| Alarm |
| 1, Air in tube, 5 grades of sensitivity (double bubble alarm); |
| 2, Bubble sensor fault; |
| 3.1, Upper-end occlusion, -20~ -60 kPa,8 grades of sensitivity; |
| 3.2, Upper-end base-pressure fault; |
| 4.1, Lower-end occlusion, 20~ 140 kPa,8 grades of sensitivity; |
| 4.2, Lower-end base-pressure fault; |
| 5.1, Pump rotation fault; |
| 5.2, Inverse-infusion; |
| 6, Abnormal door-opening; |
| 7, Low battery power, battery fault; |
| 8, Overtime pause; |
| 9, Completed infusion; |
| 10, AC power fault; |
| 11, MCU fault, and stop infusion; |
| 12, Battery temperature is too high. |
