SKF 29322 E Spherical Roller Thrust Bearing - 110 mm Bore, 190 mm OD, 48 mm Width,Self Aligning; Not Banded; Steel Cage

    Buy cheap SKF 29322 E Spherical Roller Thrust Bearing - 110 mm Bore, 190 mm OD, 48 mm Width,Self Aligning; Not Banded; Steel Cage from wholesalers

    Buy cheap SKF 29322 E Spherical Roller Thrust Bearing - 110 mm Bore, 190 mm OD, 48 mm Width,Self Aligning; Not Banded; Steel Cage from wholesalers
    • Buy cheap SKF 29322 E Spherical Roller Thrust Bearing - 110 mm Bore, 190 mm OD, 48 mm Width,Self Aligning; Not Banded; Steel Cage from wholesalers
    • Buy cheap SKF 29322 E Spherical Roller Thrust Bearing - 110 mm Bore, 190 mm OD, 48 mm Width,Self Aligning; Not Banded; Steel Cage from wholesalers

    SKF 29322 E Spherical Roller Thrust Bearing - 110 mm Bore, 190 mm OD, 48 mm Width,Self Aligning; Not Banded; Steel Cage

    Ask Lasest Price
    Brand Name : SKF
    Model Number : 29322 E
    Price : USD 0.5-10 PCS
    Payment Terms : L/C, T/T, Western Union, MoneyGram
    Supply Ability : 1000 PCS/MON
    Delivery Time : 3-15 DAYS
    • Product Details
    • Company Profile

    SKF 29322 E Spherical Roller Thrust Bearing - 110 mm Bore, 190 mm OD, 48 mm Width,Self Aligning; Not Banded; Steel Cage

    SKF 29322 E Spherical Roller Thrust Bearing

    FEATURES

    • Accommodates heavy combined load at high speeds
    • Unaffected by misalignment
    • Self-aligning
    • Separable design

    DIMENSIONS

    d
    110 mm
    Bore diameter
    D
    190 mm
    Outside diameter
    H
    48 mm
    Nominal Height
    d1
    171 mm
    Outside diameter of shaft washer end side face
    D1
    140 mm
    Shoulder diameter outer ring
    B
    30.3 mm
    Width shaft washer or length of shaft washer bore diameter that fits on shaft (bearings with a stamped steel cage)
    B1
    41.7 mm
    Height shaft washer + cage
    C
    24.8 mm
    Height housing washer
    s
    63.8 mm
    Distance from shaft washer end side face to pressure point
    r1,2
    min.2 mm
    Chamfer dimension shaft washer

    ABUTMENT DIMENSIONS

    da
    min.145 mm
    Abutment diameter shaft
    db1
    max.117 mm
    Abutment diameter spacer ring (E design bearings)
    db2
    max.117 mm
    Abutment diameter spacer ring (E design bearings)
    Da
    max.164 mm
    Abutment diameter housing
    ra
    max.2 mm
    Fillet radius

    CALCULATION DATA

    Basic dynamic load ratingC
    610 kN
    Basic static load ratingC0
    1 730 kN
    Fatigue load limitPu
    204 kN
    Reference speed
    1 900 r/min
    Limiting speed
    3 200 r/min
    Minimum axial load factorA
    0.28

    MASS

    Mass bearing
    5.3 kg


    Product Picture


    Packing , Payment , Delievry and Stock

    Packaging
    1)Commercial Bearings packaging: 1pc/plastic bag + color box + carton + pallet
    2)Industrial Bearings packaginga)plastic tube + carton + pallet
    b). plastic bag +kraft paper + carton + pallet
    3)According to the requirement of customers'
    Payment
    1) T/T:30% deposit, 70% should be paid before shipment.
    2) L/C at sight. (high bank charge, not suggest, but acceptable )
    3) 100% Western Union in advance. (especially for air shipment or small amount)
    Delivery
    1) Less than 45 KGS, we will send by express. ( Door to Door, Convenient )
    2) Between 45 - 200 KGS, we will send by air transport. ( Fastest and safest, but expensive )
    3) More than 200 KGS, we will send by sea. ( Cheapest, but long time )
    Stock
    1)Availability and supply capacity on a certain basis
