    1070nm Fiber Laser Welding Machine QBH 1000W Metal With Red Light Positioning

    Ask Lasest Price
    Brand Name : Perfect Laser
    Model Number : PE-W1000G
    Certification : CE
    Price : Negotiable
    Payment Terms : T/T, L/C, Western Union
    Supply Ability : 5000 Sets Per Year
    Delivery Time : 10-15 Working Days
    • Product Details
    • Company Profile

    1070nm Fiber Laser Welding Machine QBH 1000W Metal With Red Light Positioning

    1000W Handheld Metal Material Fiber Laser Welding Section With Red Light Positioning Function

    (Model: PE-W1000G)


    ★ Product Introduction:


    The handheld fiber laser welding machine price can weld any part of the workpiece at any angle, which is flexible and convenient, can realize outdoor welding, and is suitable for spot welding of various complex welding seams and various devices.


    ★ Features:

    1. The hand-held welding gun of fiber laser welding machine price replaces the previous fixed light path, which is more flexible and convenient, realizes long-distance laser welding, and the limitation of the travel space of the customer service workbench.

    2. The hand-held welding head of fiber laser welding machine price is light and flexible, and the operation is convenient and simple, which can meet the welding of various angles and various positions.

    3. The handheld welding head can be equipped with 5 meters, 10 meters of imported optical fiber, which is flexible and convenient to realize outdoor welding

    4. Infrared positioning is used for welding head position proofreading and position verification during welding. The welding position is more accurate and the welding seam is more beautiful.

    5. Laser welding is deep, and the welding is firm

    6.The fiber laser welding machine price is suitable for all kinds of complex welding, spot welding of various devices


    ★ Application:


    1. Applicable materials:

    The fiber laser welding machine price is used for welding of various 3mm thin metal materials.

    2. Applicable industry:

    The fiber laser welding machine price is widely used in the advertising industry, such as LED letters, advertising signs and other industries.


    ★ Technical Parameters:


    Product Namefiber laser welding machine price
    ModelPE-W1000G
    Input Voltage220V / 50HZ / 20A
    Maximum Input Power3.5 KW
    Fiber Laser Source1000 W
    Welding Thickness3mm
    Welding Head Configuration

    QBH + double water

    cooling inside

    Laser ModeContinuous / Modulation
    Laser Wavelength1070nm
    Beam Divergence Angle≤1.2mrad/m
    Welding InterfaceQBH
    Fiber Cable Length10m
    Laser Spot Diameter0.2-2mm,adjustable
    TargetingRed light
    Cooling System

    1000w water cooler inside,double circulation system,

    Heat-exchange titanium tube,over-heat alarm,

    flow protection, water level protection

    Machine Size1030x600x1200mm
    Whole Weight260 KGS
    Rated power (CW)1000(-0,+10%)W
    Operation ModeContinuous / Modulation
    Polarizationrandom
    Emission Wavelength1070nm
    RF Width< 6.0nm
    Output Power Adjustable (CW)10 - 100%
    Emission Wavelength630 - 680nm
    Maximum Output Power1.0mW
    NA (nominal)0.10
    M21.20
    Mode Field Diameter21.0Micron
    Core/Cladding Diameter20/400Micron
    Cable Length10m
    Maintainable Output Power (CW)10 - 100%
    Emission Wavelength630 - 680nm
    Maximum Output Power1.0mW
    NameNumber
    Protect Mirror10 pieces
    Filter Core1 piece
    Welding Copper Nozzle2 pieces

    ★ Machine parts:



    ★ Packaging & Delivery:


    1. Prompt deliver at the very day.

    2. Well-trained and disciplined packing team.

    3. After-sale service:. Any questions or problems after receiving the product, please feel free to contact us. Problems would be solved for you immediately.

    4. Sophisticated and professional logistic agent.


    ★ Competitive Advantages:


    1. 100% custom pass guaranteed.

    2. Our products have been exported to Germany, Norway, Poland, Finland, Spain, UK, France, Russia, USA, Brazil, Mexico, Australia, Japan, Korea, Thailand, Indonesia, Uruguay and many other countries.

    3. Flexible and Untraceable payment terms.

    4. Good after-sale service.

    5. We offer high quality products at competitive price in quick delivery.
