Main Features:
1. Flat Bottle Labeling Machine adopt mature PLC control system
technology, make the whole machine stable and high-speed,
2. This type of Automatic Labeling Machine can be suitable for square /round/oval flat bottles at the same time,
3. Use PLC touch screen control system, make operation simple, practical and
efficient,
4. Screw adjust the suppression mechanism, high accuracy,
5. Synchronization chain mechanism, to ensure smooth and precise
calibration,
6. Transparent sticker labeling without foam, adhesive sticker labeling without wrinkle,
7. Widely used and mutil-function with high flexibility,
8. Date/code printer is for optional, up to 3 lines,
9. Tranparent label sensor is for optional,
10. Can be customized according to your requirement,
11. Other match equipment: Automatic Filling Machine, Automatic
Capping Machine.
* Powerful function, one machine can realize 4 products
labeling(square, round, flat and dysmorphic bottle)
Process:
put the bottle(can be linked with the production line)—>product
orientation(automatically)—>product
delivery(automatically)—>labeling(automatically)—>collect the
labeled bottles.
No | Item | Description |
1 | Label roll inner diameter | 76mm(customized) |
2 | Max Label roll outer diameter | 370mm(customized) |
3 | Label Height | 10-190mm(optional) |
4 | Labeling speed | 36/min(adjustable) |
5 | Material | Stainless steel 316&304 |
6 | Automatic Grade | Automatic |
7 | Driven type | Electric |
8 | Power Supply | 380V,50/60HZ,3000W |
Advantage:
* The Front and Back sides bottle Labeling Machine, provided with
such mechanism as bottle Piloting, bottle dispensing and labeling,
and counting etc,is most suitable for use of small amount of
various products or for operation of single machine and single
person. The labeling position, height and angle can be adjusted. It
can be connected by conveying belt with the production line.
* With failure warning function, auto-counter technology, power
saving function(the equipment will automatic turn to power saving
holding state while no production in setting time),the production
number setting hint function and parameters setting protection
function(parameters have authority management)
Factory:
Our Servers:
We provide Turn-key project service to customer.
1. Factory Layout design;
2. Factory Decoration based on GMP standard;
3. Formula of products;
4. Raw material etc;
5. Machine design, whole production line from A to Z;
6. Shipping service, FOB, CFR, CIF etc;
7. Installation service. Training service, Maintenance service.
