    Rod End Lubricated Radial Spherical Plain Bearing GEZ304ES GEZ82ES GE304ES-2RS

    Ask Lasest Price
    Brand Name : SFT
    Model Number : GEZ304ES
    Price : negotiable
    Payment Terms : L/C, T/T, Western Union, MoneyGram
    Supply Ability : 50000PCS/MONTH
    Delivery Time : 20-45DAYS
    • Product Details
    • Company Profile

    Rod End Lubricated Radial Spherical Plain Bearing GEZ304ES GEZ82ES GE304ES-2RS

    Rod end Lubricated Radial spherical plain bearing GEZ304ES GEZ82ES GE304ES-2RS


    Product Description of Spherical Plain Bearing:


    1. Specifications:

    Radial spherical plain bearings have an inner ring with a sphered convex outside diameter and an outer ring with a correspondingly sphered but concave inside surface. Their design makes them particularly suitable for bearing arrangements where alignment movements between shaft and housing have to be accommodated, or where oscillating or recurrent tilting or slewing movements must be possible at relatively slow sliding speeds, often accompanied with heavy loads.


    2.Application:

    Rod ends are bearing units that consist of a spherical plain bearing in an eye-shaped head with integral shank:the rod end housing are used primarily on the ends of piston rods or together with hydraulic as well as pneumatic cylinders to join the cylinder to associated components.


    3 Features:

    • improves lubricant supply to the loaded zone

    • enlarges the lubricant reservoir in the bearing

    • enables relubrication under load

    • permits extended relubrication intervals

    • provides space for wear particles and contaminants to be deposited.

    Hot Sale>
    DimensionsAngleDynamicStaticDesignations
    d(inch)D(inch)B(inch)C(inch)aC(lbf)C0(lbf)Mass(lb)ModelStandard sealHigh performance
    0.50.8750.4370.37563 1509 3400.044GEZ 008 ES
    0.6251.06250.5470.46964 84014 7400.077GEZ 010 ES
    0.751.250.6560.56267 09020 9300.12GEZ 012 ES-2RS
    0.8751.43750.7650.65689 56028 5800.19GEZ 014 ES
    11.6250,8750,750612 60037 3500.26GEZ 100 ES-2RS-2LS
    1.2521.0930.937619 46058 5000.51GEZ 104 ES-2RS-2LS
    1.252.43751.391.125828 12584 3751.2GEZH 104 ES-2RS-2LS
    1.3752.18751.1871.031623 40069 7500.77GEZ 106 ES-2RS-2LS
    1.52.43751.3121.125628 13084 3800.93GEZ 108 ES-2RS-2LS
    1.52.81251.581.312738 250114 7501.75GEZH 108 ES-2RS-2LS
    1.752.81251.5311.312638 250114 7501.4GEZ 112 ES-2RS-2LS
    1.753.18751.821.5750 400150 7502.5GEZH 112 ES-2RS-2LS
    23.18751.751.5650 400150 7502.05GEZ 200 ES-2RS-2LS
    23.56252.071.687863 000191 2503.5GEZH 200 ES-2RS
