CHNT 525WP 530WP 535WP 540WP 545WP monocrystalline PV module high
power 182 F-BH series solar panels
In the field of photovoltaic, we are not only ranked top in the
production, but also lead front in the innovation.
525W-545w monocrystalline PV module, CHSM 72m(DG)/F-BH 182 series,
the newest feature is creat sustainalbe and efficient green
engergy, with +5W output positive tolerance, this is the advantage
beyond over ordinary solar panels. It was spread used to the ground
mounting system, roof mounting system, fixed adjustable mounting
system, solar thermal mountinig systme, and so on .....
We are offer you competitive price on PV modules, also give you
good warranty, 12 years warranty for materials and processing,
30years wattanty for extra linear power output. The following is
the details, you may know more clearly.
Specifications:
Power rating(front)
| 525 Wp | 530Wp | 535Wp | 540Wp | 545Wp |
Testing condition
| Front | Back | Front | Back | Front | Back | Front | Back | Front | Back |
STC rated output (P mpp /Wp)
| 525 | 368 | 530 | 371 | 535 | 375 | 540 | 378 | 545 | 382 |
Rated voltage (V mpp /V) at STC
| 41.43 | 41.48 | 41.60 | 41.65 | 41.76 | 41.81 | 41.93 | 41.98 | 42.10 | 42.15 |
Rated current (l mpp /A) at STC
| 12.67 | 8.87 | 12.74 | 8.92 | 12.81 | 8.97 | 12.88 | 9.01 | 12.95 | 9.06 |
Open circuit voltage (V oc /V) at STC
| 49.30 | 49.25 | 49.50 | 49.45 | 49.70 | 49.65 | 49.90 | 49.85 | 50.10 | 50.05 |
Short circuit current (I sc /A) at STC
| 13.40 | 9.27 | 13.48 | 9.33 | 13.57 | 9.39 | 13.66 | 9.45 | 13.75 | 9.52 |
Module efficiency
| 20.5% | 14.4% | 20.7% | 14.5% | 20.9% | 14.7% | 21.1% | 14.8% | 21.3% | 14.9% |
Temperature coefficient (P mpp )
| - 0.35%/°C |
Temperature coefficient (I sc )
| + 0.045%/°C |
Temperature coefficient (V oc )
| - 0.27%/°C |
Nominal module operating
temperature (NMOT) | 41±2°C |
Maximum system voltage (IEC/UL)
| 1500V DC |
Number of diodes
| 3 |
Junction box IP rating
| IP 68 |
Maximum series fuse rating
| 30 A |
Key Features:
► OUTPUT POSITIVE TOLERANCE:
Guaranteed 0~+5W positive tolerance to ensure power output.
►HIGH CUSTOMER VALUE:
Up to 25% additional power gain , lower BOS cost and LCOE.
► SUPER PERC+ CELL TECHNOLOGY:
Higher module power and module efficiency, lower power degradation.
► NON-DESTRUCTIVE CUTTING:
Higher bending strength of cells and mechanical properties of
modules.
► INNOVATIONAL HALF-CUT&MULTI-BUSBAR TECHNOLOGY:
Lower risk of microcrack, better shading tolerance, higher
reliability.
► APPLICABLE FOR MULTI DIFFERENT ENVIRONMENTS:
Wide range of applications, such as snow areas, high humidity areas
and strong sandstorm areas, etc..
Advantages of Solar Energy:
1. The biggest characteristic of solar energy is huge energy, the solar radiation energy reach the earth's surface is about 130
trillion tons of standard coal every year , which is equivalent to 10000 times the total amount of all kinds
energy consumed every year in the world.
2. Solar energy is a typical renewable energy, is the safest and most reliable energy.
3. The application of solar energy is not limited by mining,
transportation and storage conditions.
4. Solar energy is bound to achieve great economic importance in
future because of depletion trend of convention energy sources.
Project Reference:
Packaging and delivery:
| Module Weight | 32.3 kg |
| Packing unit | 31 pcs / box |
| Weight of packing unit (for 40‘HQ container) | 1040 kg |
| Number of modules per 40‘HQ container | 620 pcs |
► Package: strong and long distance transportation package
► Place of loading: Basic Seaport, China
► Payment Terms: L/C,D/A,D/P,T/T
► Delivery Detail: Delivery time:7--25 days after receiving
customer’s deposits
