G3/4" Durable Sand Filter Nozzle 0.25mm Slot 316L Water Treatment Filter Nozzle

G3/4" Durable Sand Treatment Slot 0.25mm Wedge Wire Strainer, Sand Filter Nozzle

Stainless steel filter screen, johnson screen nozzle, water and gas strainer nozzle, stainless steel filter nozzle, stainless steel filter candles, stainless steel lateral arms, wedge wire lateral pipes, wedge wire srainer, changeable filter element, header and hub laterals & hub radial laterals, water input device, water distributor, resign trans,etc.

Stainless Steel Filter Screen Solutions

Our range includes Johnson screen nozzles, water and gas strainer nozzles, stainless steel filter nozzles, filter candles, lateral arms, wedge wire lateral pipes, and changeable filter elements. These components are designed to enhance water input devices, distributors, and other essential systems.

Wedge Wire Screen Filter Nozzle: High Strength and Durability

Made from premium stainless steel, our wedge wire screen filter nozzles offer single and double configurations, with plate type and long handle options available. These nozzles boast high filtering efficiency, corrosion resistance, temperature resistance, and easy installation, making them ideal for a wide range of water treatment and industrial applications.

Versatile Applications

These nozzles excel in various applications, including under-drain media retention, flow distribution in demineralizers, water softening in pressure and gravity sand filters, and more. Their non-clogging design ensures efficient filtration and treatment, providing an economical and easily installed solution.

Features

• Designed for optimal filtration and treatment system performance.
• Non-clogging design for effective use in diverse applications.
• Economical, easy to install, and offers distinct design advantages.

Types of Water Filter Nozzles

1. Single head filter nozzle
2. Double head filter nozzle
3. Long handle filter nozzle
4. Double flow filter nozzle
5. Flatwater filter nozzle, etc.

Material and Specifications

• Material: Stainless steel 304, 316, 316L, 321, 904L, 2205, 2507, C276, etc. (SS304 is suitable for most environments).
• Wire Size: 1.50mm, 1.80mm, 2.00mm, 2.5mm, 3.00mm (customizable).
• Slot Size: 0.04" - 0.3".
• Diameter: 1" - 16".
• Structure: Wedge wire screen pipe + Cover plate + Thread + Nuts & Gaskets.

Applications

• Water distribution
• Tanks
• Power plants
• Water treatment
• Sand filtration
• Water softening
• Desalination

Note: All the length units are in millimeter.

Note:

1. One Nozzle with a rubber gasket, same material gasket and two thin nuts.
2. Available in customer design for perforated plate.
3. We can produce according to clients requirements.
Material: 304,321,316,316L,904L ,HastalloyB and C, ets

SUPPORT ROD						ROUND
WIDTH(mm)	1.80	2.00	2.50	3.00	3.00	Ø2.5--Ø6mm
HEIGHT(mm)	2.50	3.00	4.00	4.60	6.00	----

Benefits

• Non-clogging capabilities
• Self-supporting structure
• High abrasion resistance
• Large open area for better filtration
• Energy-efficient
• Low cost
• Long service life
• Maximum flow capacity

OEM Service

We provide tailored solutions to meet your specific needs. Contact us with your specifications, and we will deliver high-quality products. Options include:

• Material: Stainless steel 304, 316L, 321, Hastelloy B, C, etc.
• Outer Diameter: Standard sizes available, with customization options.
• Slot: 0.2mm-0.5mm, with a tolerance of +0.03mm.
• Type: Female thread (G3/4", G1"), male thread (M24 or M32), no thread, long handle, single velocity, double velocity, etc.
• Length: Standard lengths available, with customization options.

Why Choose Us?

1. Expertise: We are a professional manufacturer with years of experience.
2. Quality and Price: We offer top-tier products at competitive prices.
3. Responsive Service: Our dedicated sales team provides feedback within 24 hours.
4. After-Sale Support: We offer 12 months of excellent after-sale service.
5. Customization: We provide customized solutions to fit your unique requirements.
6. Availability: Our service is available 24/7, ensuring continuous support.

Anping county Xinlu Wire Mesh Products Co.,Ltd is located in Anping county which well knowen of “The hometown of wire mesh in China”.

We are a factory specializing in the production of wedge wire screens with 5 sets wedge wire screen machines and one set laser cutting machine. The diameter production range is from 25.4mm to 2 meters, and the minimum slot can reach 30 microns. various sizes of wedge screen orders can be accepted. All wedge wire screens surface treatment are electrolytically polished or pickled polished or galvanized. Bright, no burrs, no injury to hands. Believe it can meet your needs.

Our factory produce and sell as following: wedge wire screens, v shaped wire welded stainless steel water well screens, low carbon galvanized water well screen, Johnson screen tube, johnson screen pipe, johnson well screen, johnson wire screen, johnson filter screen, johnson v wire screens,v wire slot tube, wire wrapped screen pipe, oil well screens, dewatering well screen, perfect roundness screen tube, profile wire screen pipe, reverse rolled screen tube, spiral screen tube, screen cylinders, rod based continous slot screens, sand conrol well screen, wire wound screen pipe, stainless steel filter elements, wedge wire roll screen, stainless steel strainer pipe, sieve bend screen, arc screen plate, wire wrapped panel, flat wedge wire panel, v wire screen plate, profile wire slot panel, v wire slot panel, v wire flat screen, lauter tun screen panel, wedge wire grating, wedge wire support grids, screen beskets, filters basket, vibrating sieve screen, wire wrapped liner, water & gas filter nozzle filter nozzle, wedge wire stariner nozzle, stainless steel screen nozzle, stainless steel lateral arm, filter candle, lateral pipe, head lateral, wire wrapped nozzle pipe, water input device, resin sprayer fittings, water distributor, center distribution drainage device, single tube screen nozzle, double tube filter nozzle, Resin Traps, double loop tie wires, double wire loop ties, etc. The products are used in drilling well / pump, such as ore choosing, petroleum, chemical industry, electron, transportation, plastics, architecture, Architecture & Construction, Food & Beverage Screens, Mineral & Aggregate Processing, OEM Screen Components, Pulp & Paper Screens, Refining & Petrochemical, Waste Water Treatment, Water Well & Oil well, Salt industry, Coal, Mine, Construction rebar bundling, etc. Our products can be seen everywhere in China, Export to Ukraine, Russia, Mongolia, Iran, Pakistan, India, Japan, South Korea, Vietnam, Malaysia, Indonesia, Thailand, Colombia, Taiwan, Spain, Singapore, Costa Rica, the United States, Australia, Brazil, Germany, Mexico, Turkey, UAE,etc., the Middle East, African countries, Southeast Asia, Europe, all around the world.
