    Seated Type Reach Forklift Truck for Warehouse Handling

    Ask Lasest Price
    Brand Name : EFORK
    Model Number : CQD15E/CQD20E/CQD25E/CQD30E
    Certification : CE/CAS
    Price : us dollar 15399-24150 USD
    Payment Terms : T/T, L/C
    Delivery Time : 30
    • Product Details
    • Company Profile

    Seated Type Reach Forklift Truck for Warehouse Handling

    Seated Type Reach Forklift Truck Reach Truck Warehouse Handling Equipment

    Product specifications

    48V seating type electric reach forklift
    1.1modelCQD15E-45SCQD20E-45SCQD25E-80SCQD30E-45S
    1.2powerelectricelectricelectricelectric
    1.3operation mannerseating typeseating typeseating typeseating type
    1.4rated capacityQ(kg)1500200025003000
    1.5load centerC(mm)500500500500
    1.6front overhangX(mm)173183183183
    1.7wheelbaseY(mm)1470162016201650
    1.8reach distanceL(mm)505655515610
    2.1weight(battery included)kg3000305030505860
    3.1wheel typePolyurethanePolyurethanePolyurethanePolyurethane
    3.2front wheel∅×w(mm)267*114267*114267*114267*114
    3.3drive wheel∅×w(mm)382*142382*142382*142382*142
    3.4wheeltread,front wheelb10(mm)1180118011801332
    4.1lowered mast heighth1(mm)2105210535452485
    4.2free lifting heighth2(mm)1500150026601500
    4.3lifting heighth3(mm)4500450080004500
    4.4max. mast heighth4(mm)55005500115256945
    4.5roofguard heighth14(mm)2180218021802180
    4.6lowered fork heighth13(mm)40404040
    4.7tilt angle(front/rear)°3/53/53/53/5
    4.8overall lengthwith forkl2(mm)2465261526153169
    4.9truck body widthb1(mm)1098127012701270/1460
    4.10fork dimensions/e/l(mm)35/100/107040/122/107040/122/107045/122/1070
    4.11fork adjustmentb5(mm)210-705270-705270-705244-840
    4.12ground clearancem2(mm)70707070
    4.13aisle width,pallet1000×1200Ast(mm)2964300730073110
    4.14min.turning radiusWa(mm)1800190019001922
    5.1travel speed (unload/load)km/h7.8/6.87.8/6.87.8/6.87.8/6.8
    5.2lifting speed (unload/load)m/s0.240/0.1200.240/0.1200.240/0.1200.240/0.175
    5.3lowering speed (unload/load)m/s0.260/0.3150.270/0.3050.270/0.3050.210/0.305
    5.4max. gradeability≤10≤10≤10≤10
    5.5brakeelectromagneticelectromagneticelectromagneticelectromagnetic
    6.1drive motor powerkw6.56.56.56.5
    6.2lift motor powerkw6.36.36.38.6
    6.3battery typelead acidlead acidlead acidlead acid
    6.4battery voltage/capacitanceV/Ah48V400Ah48V400Ah48V400Ah48V400Ah
    6.5chargerV/A48V/40A48V/50A48V/50A48V/50A
    7.1drive control modeACACACAC


    1. CURTIS electric control, controller multiple automatic protection system.
    2. EPS steering energy consumption is reduced by ~20%, the operation is accurate, and the driver fatigue is reduced.
    Increase productivity.

    3. The forward-moving electric stacker is suitable for large-tonnage and high-lifting cargo storage applications. It is suitable for a variety of pallets. It has the characteristics of the overall forward movement of the mast. The turning radius is small. The obstacles at the bottom of the shelf can be ignored, and it can be suitable for narrow Channel use.
    4. The lifting joystick is in a safe lowering position, and the fork drops when it is lowered 10cm from the ground
    The speed is automatically slowed down, effectively preventing the goods from being damaged due to vibration. When the fork rises to the highest point, the buffer system reduces the vibration of the mast and improves the operator's comfort.
    5. The pedal power-off switch is used to control the operation of the vehicle. Only after the pedal power-off switch is depressed, the vehicle can be operated. Otherwise, the vehicle will stop running. This design improves the safety performance of the vehicle.
    6. 48V high-power battery, long endurance and battery life.
