    Right Angle 0B FHG Plastic Push Pull Connectors Black Chrome Plated

    Right Angle 0B FHG Plastic Push Pull Connectors Black Chrome Plated


    Raymo 0B 1B 2B FHG black chrome plated right angle circular push pull connector


    1. FHG 3 PINS PUSH PULL CIRCULAR CONNECTORS Parts Description

    0B FHG push pull connector can analogues of FHG.0B.303 LEMO connector and connector of other companies of the same type making but cheaper. RAYMO B Series Push-Pull Connectors are designed to offer a reliable connection for data, signal, and power transmissions in indoor and outdoor, 100% compatible and work well, can widely apply in Medical, Test & Measurement, Research, Communications, Broadcast Connector, Machines, Defense, Robotic, Aerospace, public sector, Information Systems, Motorsport, Miscellaneous applications.etc.

    2. Main Features FHG circular push pull connector
    • Pin and groove coding

    • 2 – 40 contacts/mixed inserts

    • Up to 6 sizes

    • Customisable with a multitude of plugs and receptacles

    • Available degree of protection: IP50

    • 5,000 mating cycles and more

    • Contacts for solder, crimp and PCB termination

    • Many different contact inserts are available

    • Cable assembly included

    3. RM-B Series Technical characteristics of Push Pull Connectors


    Technical Characteristics of push pull connector
    Temperature Range- 65° C, +200° CResistance to vibrations15 g [10 Hz - 2000 Hz]
    Shock Resistance100 g [ 6 ms]Salt spray corrosion test>144hr
    Climatical Category50/175/21Shielding (min)> 75 dB [ at 10 MHz], > 40 dB [ at 1 GHz]
    4. Alignment Key

    B series connector model part numbers are composed of three letters. FHG--The LAST LETTER indicates

    the key position and the contact type (male or female),So you also can choose FHA, FHB, FHC...Cross Reference

    PHA, PHB, PHC...

    5. Chooseing tips

    If you have purchased Lemo connector and know the original model, please tell us. We will directly offer you our corresponding one.

    If you don’t know much about the connector, please make choose according the following factors:

    • the use of the environment, indoors or outdoors, waterproof or not;
    • the panel hole size, to select the appropriate plug and socket of right dimension;
    • the current-voltage, number of contact and the realization of the function, to determine the contact(cores) ;
    • select the appropriate clamp diameter and sheath;
    • according to the actual needs of different angles of the keys, to determine the keying .
