12.3 Inch TFT LCD Display RGB Color Ultra Wide Stretched Bar LCD
12.3 Inch Tft Lcd Display Resolution 1920 720 Lcd Modules Ultra
Wide Stretched Bar Lcd
1. Specification
| Product Name | 12.3 inch Stretched Bar Lcd |
| Number of Dots | 1920*720 |
| TFT Active area | 29.2032 (H) x 10.9512 (V) cm |
| Module Size | 12.3 Inch |
| Color Type | RGB |
| Color | 16.7 M |
| Peripheral size | 29.6032(H) x11.8844(V) x0.103(T) cm |
2. Description
ChengHao Display model CH123HAX04 is a color active matrix thin
film transistor (TFT) liquid crystal display (LCD) that uses
amorphous silicon TFT as a switching device. This model is composed
of a TFT LCD panel, a driving IC, a high brightness back-light and
FPC.
This TFT LCD has a 12.3 (Landscape screen) inch diagonally measured
active display area with 1920*720 resolution and can display 16M
colors. The driver is mounted on the glass and the interconnection
via FPC including components to drive the display module. Support
RGB interface.
In addition, FPC can also be customized according to customer
requirements, such as modifying back-light, interface definition,
etc.
RoHS Compliance & Halogen Free.
3. Drawings
4. Application
CH123HAX04A is a 1920*720 pixel high-definition TFT LCD display,
which is widely used in car navigation/industrial
equipment/artificial intelligence and smart home.
5. Our Service
(1) Fully / Semi-automated production line ensure the best quality.
(2) Custom Design,can specially meet your needs.
(3) Fast Delivery ,about 20 days for lead time
(4) Samples available on request; Small MOQ orders can be
negotiated.
(5) Provide best pre-sale and after-sale service to you.
6.Our Product
(1). Module
* Size:
1.44"/1.50"/1.54"/1.77"/1.80"/2.0"/2.1"/2.31"/2.40"/2.80"/3.50"/3.90"/3.95"/3.97"/3.98"/4.0"/4.3"/5.0"/5.5"/6.0"/7.0"/8.0"/9.0"/10.1"
* Shape: Round shape/Square(Horizontal/vertical)
* Interface: MIPI / RGB/ SPI / MCU
* Number of Dots: Optional
* Brightness
Regular: 100-500 nits
Sun Readable: 500-1000 nits
(2). Touch Panel
* Touch Type: Non touch / Resistive touch / Capacitive touch
* Interface Type: I2C / USB
(3). Logo: Silk-screenedI aser Engraved
(4). Glass: Anti-Reflective/Anti Glare/Vandal-resistant
(5). Interface: HDMI/VGA/DVIUSB/BNC
7. FAQ
Q: Are you open to OEM processing?
A: YES!
Q: Payment Terms?
A: Paypal can be accepted for sample, but Credit Card and T/T paid in advance for mass production.
Q: What is your delivery method?
A: DHL/ UPS / FEDEX/TNT , Or ship the goods to your HK forwarder.
Q: Products are in stock?
A: Our inventory is mainly raw materials,semi-finished and a small
amount of finished products.
Q: How long can you deliver?
A: After payment, Samples available in stock will be sent within 3
days; Small batch delivery takes 2-3 weeks; Large batch delivery
takes 5-6 weeks
Q: What kind of packaging? The transport process will not be damaged?
A: Our products are divided into two categories, small - medium
size use knife card isolation packaging, large size screens are
used in aircraft box packaging, all packages are protected by outer
box and strapping to ensure the safety of material
transportation.
