    Automation Control 110kw 150hp VFD Variable Frequency Drive With LCD Keypad

    Ask Lasest Price
    Brand Name : VEIKONG
    Model Number : VFD500-110G/132GT4
    Certification : CE, ROHS
    Price : Please contact quotation
    Payment Terms : T/T, Western Union, L/C
    Supply Ability : 1000 units per week
    Delivery Time : depends on quantities
    • Product Details
    • Company Profile

    Automation Control 110kw 150hp VFD Variable Frequency Drive With LCD Keypad

    110kw 150hp variable frequency drive vector control for heavy load​


    Product Advantage


    1. Energy saving


    2. Soft starter


    3. Machines operating protection


    4. Automation control


    5. Enhance the production efficiency


    VFD application range: Fans, Blowers, Turbines, Blast furnace, Water Pumps, Oil pumps, Plastic extruders, Granulating machine, Industrial production lines, Industrial washing machines, CNC machine, Spinning frame, Roving frame, Dyeing and printing machinery, Escalator, Medium requirement applications, Crane application, Metal cutting machine...

    VFD500 technical data:
    ItemSpecifiation
    InputInuput Voltage

    1phase/3phase 220V:200V~240V

    3 phase 380V-480V:380V~480V

    Allowed Voltage fluctuation range-15%~10%
    Input frequency50Hz / 60Hz,fluctuation less than 5%
    OutputOutput Voltage3phase:0~input voltage
    Overload capacity

    General purpose application:60S for 150% of the rated current

    Light load application:60S for 120% of the rated current

    ControlControl mode

    V/f control

    Sensorless flux vector control without PG card(SVC)

    Sensor speed flux vector control with PG card (VC)

    Operating modeSpeed control,Torque control(SVC and VC)
    Speed range

    1:100 (V/f)

    1:200( SVC)

    1:1000 (VC)

    Speed control accuracy

    ±0.5% (V/f)

    ±0.2% (SVC)

    ±0.02% (VC)

    Speed response

    5Hz(V/f)

    20Hz(SVC)

    50Hz(VC)

    frequency range

    0.00~600.00Hz(V/f)

    0.00~200.00Hz(SVC)

    0.00~400.00Hz(VC)

    Input frequency resolution

    Digital setting: 0.01 Hz

    Analog setting: maximum frequency x 0.1%

    Startup torque

    150%/0.5Hz(V/f)

    180%/0.25Hz(SVC)

    200%/0Hz(VC)

    Torque control accuracy

    SVC:within 5Hz10%,above 5Hz5%

    VC:3.0%

    V/f curve

    V / f curve type: straight line, multipoint, power function, V / f separation;

    Torque boost support: Automatic torque boost (factory setting), manual torque boost

    Frequency giving ramp

    Support linear and S curve acceleration and deceleration;

    4 groups of acceleration and deceleration time, setting range 0.00s ~ 60000s

    DC bus voltage control

    Overvoltage stall control: limit the power generation of the motor by adjusting the output frequency to avoid skipping the voltage fault;


    Undervoltage stall control: control the power consumption of the motor by adjusting the output frequency to avoid yaw failure


    VdcMax Control: Limit the amount of power generated by the motor by adjusting the output frequency to avoid over-voltage trip;

    VdcMin control: Control the power consumption of the motor by adjusting the output frequency, to avoid jump undervoltage fault

    Carrier frequency1kHz~12kHz(Varies depending on the type)
    Startup method

    Direct start (can be superimposed DC brake); speed tracking start


    Replace famous brands vfd in general application.



    VEIKONG 110kw application picture

    16 Group Energy saving control
    r16.00Electricity meter count (32BIT)Unit:KW/H-
    r16.02Output powerUnit:0.1kw,output power will be negative in regen state-
    r16.03Power factor-1.000~1.000-
    P16.04Electricity meter zero clearing0:no function;1111:clear to zero0
    P16.05Energy saving control0:disable
    1:enable
    0
    P16.06Energy saving voltage limit0%~50%(0% means Energy saving control disable and more than 0% means Energy saving control enable0%
    P16.07Energy saving filter time0.0~10.0s2.0s
    Notice:P16.05 is invisible(it is useful in vf control) and When energy saving enabled, the output current can be reduced and thepower loss can be reduced when the load is light.For example, the fan and pump is light loaded, most of the inverters do not have this function, so we are more energy efficient. Energy savings can be achieved when it is light loads or load changes so slow
