    IEEE 802.11b WIFI Router Module

    Ask Lasest Price
    Brand Name : Createk
    Model Number : ITWM202
    Certification : CE, RoHS, FCC, KC
    Payment Terms : T/T, Western Union
    Supply Ability : 100 kpcs/ month
    Delivery Time : 5 weeks
    Price : USD15.9
    • Product Details
    • Company Profile

    IEEE 802.11b WIFI Router Module

    Router wifi module 300Mbps MTK chipset with rich interface best RF performance widely use


    Model Number: ITWM202

    WIFI module ITWM202_300M AP/ROUTER module 7628

    IEEE 802.11b/g/n (2T2R)300Mbps AP/ROUTER Module


    General Description:


    ITWM202 is a wireless router WIFI module, designed base on MT7628NN chipset . fully complies with IEEE 802.11b/g/n standards ,it can be applied in the fields of IP camera , smart home and IOT. It support both wire and wireless connection, wireless transmission rate can reach up to 300Mbps , It has rich interface, which can solve the monitoring audio and video services better , and it has excellent RF performance and wireless transmission is more stable.


    Application:


    l IP Camera

    l Security monitor

    l wireless security NVR systems

    l Intelligent wireless control

    l Smart house


    Features


    l Operating Frequencies : 2.4~2.4835GHz

    l IEEE Standards : IEEE 802.11b/g/n

    l Wireless data rate can reach up to 300Mbps

    l Connect to the external antenna through i-pex connector

    l Power Supply:3.3V±0.2V


    Module specifications


    ItemDescription
    Product NameITWM202
    Main ChipMT7628NN
    ChipFlash@4MB(32MB Optional); DDR2@64MB(128MB Optional)
    Host InterfaceWAN/LAN,USB2.0,I2C, SPI Card,2*UART, 1*GPIO,5*LED,RESET
    IEEE StandardsIEEE 802.11b/g/n
    Operating Frequencies2.4GHz~2.4835GHz

    Modulation

    802.11b: CCK, DQPSK, DBPSK

    802.11g: 64-QAM,16-QAM, QPSK, BPSK

    802.11n: 64-QAM,16-QAM, QPSK, BPSK

    Working ModeRouter(Default Router)

    Wireless Data Rate

    802.11b: 1, 2 ,5.5,11

    802.11g: 6,9,12,18,24,36,48,54

    802.11n: MCS0~7,HT20 reach up to72.2Mbps, HT40 reach up to150Mbps HT40 reach up to300Mbps (2T2R)

    Rx Sensitivity-98dBm (Min)
    TX Power19.5dBm (Max)
    Antenna Typeconnect to the external antenna through i-pex connector
    Dimension(L*W*H)33.0 mm *18.0 mm *2.2mm, Tolerance: ±0.15mm
    Power Supply3.3V±0.2
    Clock Source40MHz
    Working Temperature-10°C to +50°C
    Storage Temperature-40°C to +70°C
    Quality IEEE 802.11b WIFI Router Module for sale
