10-20T/H Dry Mortar Mix Batching Plant Tile Adhesive Making
Manufacture
1. Description Of MG Automatic Dry Mix Mortar Batching Plant:
MG Dry mortar plant is a set of equipment that is designed to mix
dried sand, cement, thickening powder, fly ash, and other
functional additives together according to different recipes. The
plant produces bagged or bulks dry mortar, which can be applied
directly after mixed proportionally into the water and stirred for
a while.
The Production Capacity You Can Choose
A) 3t/h dry mortar production line
B)4-5t/h dry mortar production line
C)6-8t/h dry mortar production line
D)10-12t/h dry mortar production line
E)20-25t/h dry mortar production line
F)30t/h dry mortar production line
G)40-50t/h dry mortar production line
2. Configuration Of MG Full Automatic Dry Mix Mortar Batching Plant
Raw material silos : cement,sand, caco3a and some additives
Feeding screw: the speed can by controlled by frequency converter
Quantity dosing system: auto-dosing all raw material accurately
Mixing system: double-shaft paddle mixer ,plough mixer ,ribbon
mixer or others
Packaging machine: valve-bag packing machine,open-mouth bag packing
machine and others
Dust collecting system: installed at the position of feeding port,
packing port
Automation control system: PLC+TOUCH SCREEN
3. Parameter of MG Full Automatic Dry Mix Mortar Batching Plant:
| Model | 2000L Mixing plant | 3000/4000L Mixing plant | 6000L Mixing Plant | 10000L Mixing Plant |
| Capacity | 10-12T/H | 15-30T/H | 30-40T/H | 50-60T/H |
| Machine Height | 8-9m | 9-10m | 11-12m | 13-15m |
| Total Power | 80-90KW | 90-100KW | 100-120KW | 120-150KW |
| Worker Required | 2-3 person | 3-4 person | 3-4 person | 3-4 person |
| Workshop Required | 500-600㎡ | 600-800㎡ | 800-1000㎡ | 1000-1500㎡ |
| Bag belt Conveyor | B500X5000mm | B500X5000mm | B500X5000mm | B500X5000mm |
| Pallet Wrapping Machine | Provide | Provide | Provide | Provide |
| Sand Dryer | Provide As Requirement | Provide As Requirement | Provide As Requirement | Provide As Requirement |
| HS Code | 8474390000 | 8474390000 | 8474390000 | 8474390000 |
4. Advantage of MG Automatic Dry Mix Mortar Batching Plant:
(1)There are several materials discharging modes for selecting,
which include the manual mode, electrical mode and pneumatic mode.
(2)The fiber can be rapidly separated by the high speed rotating
blades.
(3)The air-phase balancing device is installed to mix the materials
more even.
(4)The compound structure of paddles can largely reduce the cost of
maintenance.
(5)The materials are discharged through the big gate, which can
reduce the blind areas inside the mixer, make the discharging
procedure cleaner and faster.
(6)It can mix the solid-solid (powder and power) and solid-liquid
(powder and liquid), and also take drying operation.
(7)The speed of mixing is fast, it only takes about 2-3 minutes to
mix the ordinary powders.
(8)The machine can be operated in confined space, which is running
reliably and convenient in maintenance.
5. Application of MG Automatic Dry Mix Mortar Batching Plant:
The dry mortar production line can produce the following dry
mortars:
Bonding mortar: Masonry mortar, wall and floor tile adhesive
mortar, anchorage mortar etc.
Decoration mortar: Decorative plaster, inner and outer wall putty,
colorful decoration mortar etc. Protection mortar: Water-proof
mortar, anti-corrosion mortar, self-leveling mortar, wear
resistance mortar, thermal insulation mortar, sound insulation
mortar, repair mortar, mildewproof mortar, shielding mortar etc.
6. Customer Visits
7. Certificates
8. Our Company
Zhengzhou MG industrial Co., Ltd, the leader of Full Automatic dry
mix mortar plant!
Zhengzhou MG industrial Co., Ltd, was verified by ISO9001 quality
control system, awarded as Henan first-class science and technology
enterprise by government. We were Henan observe quality and
credibility enterprise union governing unit in 2012.
Our company engaged in the dry powder mixing equipment R&D,
production, sales and construction, providing most efficient
turnkey solutions to our clients in green building energy-saving
insulation and green wall (building) materials manufacturing
equipment, production technology and construction program.
Our main products include dry mortar production line, thermal
insulation mortar production line, sand dryer, powder blending
machine, concrete mixer, and others.
9. Why Choose Us
