    Mini Reversible Hammer Crusher Machine For Gold Ore Rock Stone Quarrying

    Ask Lasest Price
    Brand Name : ZR
    Model Number : PCD
    Price : Price Negotiable
    Payment Terms : T/T
    Supply Ability : 1000PCS/Year
    Delivery Time : 20-30 days
    • Product Details
    • Company Profile

    Mini Reversible Hammer Crusher Machine For Gold Ore Rock Stone Quarrying

    PCD8080 Mini Mining Ultrafine Crusher


    Technical Parameters

    Model: PCD8080

    Max Feed Size: 80mm

    Production Capacity Of Clinker: 25-30t/h

    Production Capacity Of Limestone: 30-40t/h

    Average Discharge Size: 3mm

    Motor Power: 45kw


    Technical Parameters Of PCD Serial

    ModelMax feed
    (mm)
    Treat capacity(T/H)Average
    Discharge granularity
    (mm)
    Power
    (kw)
    Dimension(mm)
    ClinkerLimestone
    PC-D-8040<8015~2020~253371395*1506*1390
    PC-D-8080<8025~3030~403451395*1906*1390
    PC-D-9080<10040~4545~503451754*1906*1659
    PC-D-9010<10045~5050~553551754*2176*1659
    PC-D-1010<15050~6060~703~5902138*2590*2021
    PC-D-1210<20060~8070~903~51102524*2716*2325
    PC-D-1212<20060~10070~1103~51322524*2866*2325
    PC-D-1414<20070~15070~1605~82002550*3120*2670
    PC-D-1616<200100~210110~2605~82502922*3564*2900
    PC-D-1818<200120~270130~3105~103153121*3754*3150

    Profile
    The series of crushers combines the technical advantages of crushing equipment at home and abroad, through development and improvement to make the structure design more optimized. Reasonable three-room broke chamber combination, novel regulation mechanism, the product size is fine and even due to effective control, convenient maintenance equipment, and the hammerhead and the sieve plate can be replaced conveniently.


    Product Usage

    Usage of PCD series ultrafine energy saving crusher: Widely used in chemical, building materials, metallurgy, mining, coal processing, sand making, and refractory industries; High-efficiency fine crushing to treat medium hardness material such as limestone, cement clinker, shale, dolomite, granite, gypsum, mixed materials, etc.
