DN15-DIN600 Stainless Steel Pipe Fittings Flanges High Pressure Flange

    Buy cheap DN15-DIN600 Stainless Steel Pipe Fittings Flanges High Pressure Flange from wholesalers

    Buy cheap DN15-DIN600 Stainless Steel Pipe Fittings Flanges High Pressure Flange from wholesalers
    • Buy cheap DN15-DIN600 Stainless Steel Pipe Fittings Flanges High Pressure Flange from wholesalers

    DN15-DIN600 Stainless Steel Pipe Fittings Flanges High Pressure Flange

    Ask Lasest Price
    Brand Name : DN15-DIN600 High pressure flange
    Model Number : LJ-PF446
    Certification : ISO9001
    Price : Negotiation
    Payment Terms : L/C, T/T
    Supply Ability : Annual output 50000 tons
    Delivery Time : Depends on the quantity of goods
    • Product Details
    • Company Profile

    DN15-DIN600 Stainless Steel Pipe Fittings Flanges High Pressure Flange

    Stainless Steel Flanges DN15-DIN600 High pressure flange

    Description


    High pressure flange is used for connecting pipes or equipment with pressure higher than 10MPa. At present, it mainly includes traditional high-pressure flange and high-pressure self tightening flange.

    High pressure flange is a part that uses the plastic deformation of the sealing gasket (elliptical gasket, octagonal gasket, lens gasket, etc.) to achieve the sealing effect, and is connected to the pipe end to connect the pipe with the pipe. There are holes on the flange, and the two flanges are tightly connected by stud bolts.

    Technical data sheet


    Carbon Steel Pipe Fittings ASTM A234 carbon steel tee technical data sheet as below:

    DNPM1.6MPa(16bar)PN2.5MPa(25bar)
    external diameterDiameter of bolt hole center circleBolt hole diameterBolt threadquantityexternal diameterDiameter of bolt hole center circleBolt hole diameterBolt threadquantity
    10906014M124906014M124
    15956514M124956514M124
    201057514M1241057514M124
    251158514M1241158514M124
    3214010018M16414010018M164
    4015011018M16415011018M164
    5016512518M16416512518M164
    6518514518M16418514518M168
    8020016018M16420016018M168
    10022018018M16423519022M208
    12525021018M16827022026M248
    15028524022M20830025026M248
    20034029522M20836031026M2412
    25040534426M241242537030M2712
    30046041026M241248543030M2716

    Characteristic


    1. The sealing principle belongs to plastic deformation.

    2. Connected by bolts.

    3. Bolts should bear tensile force, temperature difference stress, bending moment, torque and many other external stresses.

    4. The volume is huge, the weight is heavy, and the installation and positioning is very difficult.

    5. The sealing performance is unstable, especially under harsh conditions (high temperature, high pressure and highly toxic medium), it is easy to leak, resulting in serious consequences.

    StandardANSIANSI B16.5 ASME B16.47 series A/B
    DINDIN
    ENEN1092-l:2002
    MaterialANSICS A105/SA 105NSS 304/304L, 316/316L Alloy Steel: WHPY45/52/65/80
    DINCS RST37.2;S235JR SS 304/304L.316/316L
    ENCS RST37.2;S235JR;C22.8SS 304/304L,316/316L
    PressureANSIClass 150, 300, 600, 900, 1500 2500lbs
    DINPN6,PN10,PN16>PN25,PN40>PN64,PN100
    ENPN6,PN10,PN16>PN25,PN40>PN64,PN100
    SizeANSI1/2" - 60”
    DINDN15-DN2000
    ENDN15-DN2000

    Package


    Delivery
