HFSecurity RA08T Wireless Android 7 OS Detecting Distance Face
Temperature Detection And Recognition Device
is HFSecurity newest 8 inch touch screen dynamic dual face live scan time
attendance access control with temperature ;Android 7 OS,supports
Ethernet
and WIFI connection.It can detect 5 moving persons at 5 meters within 0.7
seconds,IP64 level,work outdoor and mainly be designed for
turnstile system.
NEW function: Temperature Detection
| Screen |
| Dimension | 8 inches touch screen, full view angle, IPS LCD screen |
| Resolution | 1280×800 |
| Camera |
| Dual Camera | 2.0M (RGB Camera) ; 1.0M (Infrared Camera) |
| Type | Wide dynamic camera |
| Aperture | 4mm |
| Focal Length | 0-2m |
| White Balance | Automatic |
| Wide Dynamic | Support |
| Vertical Wide Angle |  |
| Horizontal Angle |  |
| Core Parameter |
| CPU | 4 cores, 1.8GHz |
| Memory | 2GB RAM, 8GB ROM |
| OS | Android 7 |
| Accessories |
| Filling Light | LED filling light |
| Card Reader (Optional) | Ic card reader |
| Network Module | Support wired, wireless (2.4G Wi-Fi),optional 4G |
| Interface |
| Audio | 1 channel audio output (line out) |
Serial Communication Interface | RS232 |
| Interface | USB 2.0, RJ45, Externale QR Code |
| Relay Output | Support |
| Wiegand Interface | support Wiegand 26/34 input /output |
| Reset Interface | Yes |
| Function |
| Face Detection | Support detecting and tracking 5 people at the same time |
| 1:N Face Recognition | 99.99% |
| Face Capacity | 20,000 |
1:1 Person Certificate Comparison | More than 99% |
| Temperature detection | Support |
| Stranger Detection | Support |
| Remote Upgrade of Equipment | Support |
| Recognize Distance | Support |
| Protection Level | IP64, certain dustproof and waterproof function |
| General Parameters |
| Power Supply | DC12V (±10%) |
| Operating Temperature | 16℃~30℃ |
| Working Humidity | 10% to 90% |
| Power Consumption | 10W MAX |
| Installation Method | Turnstile, Wall mounted, Desktop, Floor Type |
| Device Size | 234(L)*125(W)*24.5(H)mm |
| Weight | 3KG (Device Only) |
Face Recognition Time Attendance and Access Control
• 8 inch touch screen
• IP64 Waterproof,
• Support wired, wireless (2.4G Wi-Fi), optional 4G, QR Code
