Brand Name : | Joinwit |
Model Number : | JW4106N |
Certification : | CE/ROSH/IOS9001 |
Price : | Negotiable |
Supply Ability : | 500sets |
Delivery Time : | 5-8 work days |
JoInwit fusion splicer JW4106N FTTH Welding splicing machine
Product Description:
Obtaining 16 patens of invention and 58 technical innovations, a
brand-new product—4106S Optical Fiber Fusion Splicer is launched,
thanks to 5 years of painstaking research of 28 engineers.
4106S implements industrial-grade CPU+FPGA structure of
high-performance, completely fresh HD optical fiber microscope,
imported high-speed motor and aluminum-magnesium alloy materials
extensively.
Compared with TW4106, our start product, TW4106S lowers the size by
38%, the weight by 52%, the power consumption by 57%, but improves
the speed by 60%, the environment adaptability by 80% and the
reliability (MTBF) by 200%.You can get unprecedented fusion
splicing experience.
Optical Specifications | 4106S |
Fiber heater | Effective heating length: ≤60mm Heating time: 10s~255s, settable as required. Typical heating time: ≤25s(standard 40mm sleeve),≤28s(standard 60mm sleeve). |
Power supply | External DC power input Input voltage is 13.5±0.5V; input current≥4.4A; socket center is positive. Built-in lithium-ion battery for power supply. The lithium-ion battery is 11.1V, ≥5.2Ah, full charging time is approx. 2.5h. |
Dimensions and weight | Dimensions: W×H×D=120mm×130mm×154mm(without vibration-free rubber
pad) Weight:approx.1.95kg(with the lithium-ion battery), approx.1.75kg(without the lithium-ion battery). |
Environmental conditions | Operating temperature: -10C~+50C Temperature limit: -20C~+55C Operating humidity: 95%RH and below(non-condensing) Max. wind speed: 15m/s Storage temperature: -40C+80C, Storage humidity: 95%RH and below (non-condensing). |
Splice loss | Typical loss values of spliced points are: Single-mode fiber: 0.03dB Multi-mode fiber: 0.01dB Dispersion shifted fiber: 0.04dB Non-zero dispersion shifted fiber: 0.04dB Typical splice time: 7s(FAST mode, typical) Monitor: with touch screen function, 4.3 inch TFT color LCD USB port: system update and data transmission Real-time display of remaining battery capacity Built-in lighting with high brightness, for convenient loading of fibers |
![]() |
