The GSCC supports the system control, orderwire, communication, and
system power supply monitoring.
Table 1 provides the functions and features of the GSCC.
Table 1 Functions and features of the GSCC
Function and Feature
GSCC
Basic functions
Performs the service configuration function and service grooming
function, monitors the service performance, and collects
information about performance events and alarms.
Interfaces
Provides the 10M/100M Ethernet port, which is used for
communicating with the NMS. The Ethernet port is accessed through
the AUX.
Provides the F&f interface, which is accessed through the AUX
and is used to manage the COA.
Provides one 64 kbit/s synchronous data port F1, which is accessed
through the AUX.
Provides the RS232 OAM interface, which is used for connecting a PC
or workstation, and supports the remote maintenance by using a
modem that uses the RS232 DCE interface. The OAM interface is
accessed through the AUX.
DCC communication
Processes a maximum of 160 DCCs (D1-D3). In this manner, the link
is provided for transmitting the NM information.
Overhead processing
Processes the E1, E2, F1, and serial1-serial4 bytes.
Clock function
Provides the RTC.
Supports the high-precision clock synchronization feature, and
complies with the IEEE 1588 V2 protocol. The N4GSCC receives the
time information through interfaces S1-S4 of the AUX. The S1, S3
and ALMI4 interfaces receive the first channel of time information,
and the S2, S4 and ALMI4 interfaces receive the second channel of
time information.
Alarms and maintenance features
Supports service performance monitoring and collects information
about performance events and alarms.
Provides 16 alarm inputs and four alarm outputs through the AUX.
Provides one 4-output alarm cascading port through the AUX.
Controls the four cabinet indicators through the AUX.
Supports intelligent fan speed control and manages the fan alarms.
Supports simulation package loading and diffused loading.
Supports the function of detecting whether a packet data board is
in position.
Power supply management
Supports the monitoring of the -48 V or -60 V power supply.
Supports the in-service check function for the PIU board and
supports the failure check function for the lightning protection
module of the PIU.
Protection schemes
Supports the 1+1 Hot Backup for the SCC Unit. When the active board
is faulty, services are switched to the standby board
automatically.
NOTE:
If GSCC boards are used in packet systems, two N4GSCC/N6GSCC boards
of the same version need to be configured in 1+1 backup mode.
Packet function
The N4GSCC and N6GSCC support the packet function.
For information about the performance of the packet system, see
Packet System Performance.
Technical Specifications of the GSCC
The technical specifications of the GSCC include the mechanical
specifications and power consumption.
Mechanical Specifications
The mechanical specifications of the GSCC are as follows:
Dimensions (mm): 25.4 (W) x 235.2 (D) x 261.4 (H)
Weight of the N4GSCC (kg): 1.0
Weight of the N6GSCC (kg): 0.9
Power Consumption
The maximum power consumption of the GSCC at room temperature
(25°C) is 19 W.
