Supports tunable wavelength optical modules that provide for:
40 wavelengths tunable in the C band with 100 GHz channel spacing
80 wavelengths tunable in the C band with 50 GHz channel spacing
ESC function
Supported
PRBS test function
Supports the PRBS function on the client and WDM sides.
LPT function
Not supported
FEC encoding
TN11TMX:
Does not support FEC on the client side, when the client side
service type is OTU1.
Supports ITU-T G.709-compliant forward error correction (FEC) on
the WDM side.
Supports ITU-T G.975.1-compliant advanced forward error correction
(AFEC) on the WDM side.
TN12TMX:
Does not support FEC on the client side, when the client side
service type is OTU1.
Supports ITU-T G.709-compliant forward error correction (FEC) on
the WDM side.
Supports ITU-T G.975.1-compliant AFEC-2 on the WDM side.
NOTE:
Boards that use different FEC modes cannot interconnect with each
other.
Alarms and performance events monitoring
Monitors BIP8 bytes (Bursty mode) to help locate line failures.
Monitors B1 bytes to help locate faults.
Monitors OTN alarms and performance events.
Monitors parameters such as the bias current, temperature, and
optical power of the laser.
Regeneration board
The WDM-side signals from one TN11TMX board can be regenerated by
another TN11LSXR board.
The WDM-side signals from one TN12TMX board can be regenerated by
another TN12ND2/TN52ND2/TN53ND2/TN55NO2/TN53NQ2/TN54NQ2 board.
ALS function
Supports the ALS function on the client side.
Test frame
Not supported
Latency measurement
Not supported
Optical-layer ASON
Supported
Electrical-layer ASON
Not supported
Protection scheme
Supports client 1+1 protection.
Supports intra-board 1+1 protection (when working with the
OLP/DCP/QCP board).
Supports OWSP protection.
Loopback
WDM side
Inloop
Supported
Outloop
Supported
Client side
Inloop
Supported
Outloop
Supported
Protocols or standards compliance
Protocols or standards for transparent transmission
(non-performance monitoring)
ITU-T G.707
ITU-T G.782
ITU-T G.783
GR-253-CORE Synchronous Optical Network (SONET) Transport Systems:
Common Generic
Protocols or standards for service processing (performance
monitoring)
ITU-T G.805
ITU-T G.806
ITU-T G.709
ITU-T G.872
ITU-T G.7710
ITU-T G.798
ITU-T G.874
ITU-T M.3100
ITU-T G.874.1
ITU-T G.875
ITU-T G.808.1
ITU-T G.841
ITU-T G.8201
ITU-T G.694.1
Mechanical Specifications
Dimensions of front panel (H x W x D): 264.6 mm (10.4 in.) x 25.4
mm (1.0 in.) x 220 mm (8.7 in.)
Weight:
TN11TMX: 1.4 kg (3.1 lb.)
TN12TMX: 1.1 kg (2.4 lb.)
Power Consumption
Board
WDM-Side Optical Module
Typical Power Consumption (W)
Maximum Power Consumptiona (W)
TN11TMX
800 ps/nm-C Band (odd & even wavelengths)-Fixed Wavelength-NRZ-PIN
800 ps/nm-C Band-Fixed Wavelength-NRZ-PIN
40.3
44.3
1200 ps/nm-C Band-Tunable Wavelength-NRZ-PIN
1200 ps/nm-C Band-Tunable Wavelength-NRZ-APD
42.1
46.4
800 ps/nm-C Band-Tunable Wavelength-(D)RZ-PIN
44.5
51.2
4800 ps/nm-C Band-Tunable Wavelength-ODB-APD
48.4
55.7
TN12TMX
800 ps/nm-C Band (Odd & Even Wavelengths)-Fixed
Wavelength-NRZ-PIN-XFP
10 Gbit/s Multirate-10 km-XFP
10 Gbit/s Multirate-40 km-XFP
10 Gbit/s Multirate-80 km-XFP
31.4
36.1
800 ps/nm-C Band-Tunable Wavelength-NRZ-PIN-XFP
32.4
37.1
800 ps/nm-C Band-Tunable Wavelength-(D)RZ-PIN
41
45.5
800 ps/nm-C Band-Tunable Wavelength-NRZ-PIN
39
43.7
a: The maximum power consumption is the power consumed by the board
when it works normally under the highest ambient temperature.
