Explosion LED Floodlight Class I Division 2 Group A, B, C, D 200W
Aluminum Gray color
LEDSION Hazardous Flood Light use best die-casting aluminum
housing, anti-corrosion painting IP65 design. High-performance
illumination that lasts 50,000HRS.10KV surge protection. Replace
300-1000W MH/HPS.
Main Features:
1. High Efficacy low decay 700MA LED chip
2. High heat transmit die cast housing ADC12 aluminum, patent
design, IP68
3. Shock and vibration resistant tempered glass, super clear 95%
light transmit rate
4. Anti-glare.Scientific optical reflector design, making the light
more focus,even, comfortable for eyes
5. Original Bridgelux LED source,high luminous efficacy and long
lifespan
6. MEANWELL HLG series driver, the highest level of MEANWELL driver
7. Surface treatment-Powder painted, salt resistant and chemical
resistant, also hard for dust to accumulate on the surface
8. 2.0mm aluminum PCB with heat index 2.5, keep LED working under
cool temperature
9. Working temperature: -30ºC to 50ºC.
10. IK09 robust design.
11. UL certified housing, suitable for marine.
Packing & Shipping:
- Customized packing are available, different MOQ according to
different model.
- Regular sample will be ready in 24 hours, regular order delivery by
express / sea/ air accordingly.
- Shipping from Dallas warehouse, by express: 3-5days, by truck:
5-7days normally, differenct address different shipping time.
- Shipping from China factory, by express: 3-7 days normally;
shipping by air: 8-15 days normally; shipping by sea, 15-35 days
accordingly.
Specification:
| |
| |
| |
| |
| |
| |
| |
| |
| - Gray/Green/Yellow/Customized
|
| |
| |
| |
| |
| |
Photometrics:
1. U shaped bracket
2. Adjustable Wall/Ceiling Mount Plate
3.High bay mount hook
4.Recessed mount holder
Installation:
- Fixture is equip with Bracket
- Connection outlet conduit: 3/4” NPT
- Conduit and pole are not included in products.
- All installation must conduct by qualify electrician.
- Seal must be placed in each conduit
Product Dimension(mm):
Applications:
1. Suitable for gas station, petroleum and chemical industries,
coal mine, military, airport, warehouse, marine etc.
2. Zone1 & Zone2 gaseous environment, and Zone21 & Zone22 dust
environment.
3. Class I Division 2 Group A, B, C, D
Warehouse introduction:
Ledsion Ligting has its own warehouse in Dallas, TX 75247, USA.
Warehouse area up to 50,000 square feet. We have professional
person responsible for warehouse operation. Professional
after-sales service, and professional logistic team, can send out
all the goods in the same day customer ordered.
