Customized Cheap Durable Steel Structure
Warehouse/Workshop/Shed/Hangar/Hall Buildings
Steel structure building is a popular type of building system now,
and its main load-bearing members are made of steel, including
column, beam, foundation and roof truss, while roof and wall using
variety of materials, such as sandwich panel, steel sheet, wire
mesh, foam cement board, ALC board for different building
application.
| Steel structure building |
| Q345, Q235, Q345B, Q235B etc Welded H section steel column and beam
with 2 times mid-grey anti-rusting painting |
| Galvanized C purlin, tie bar, brace, roof and wall support |
| Anchor bolt, High strength bolt, Ordinary bolt |
| a) Color-coated corrugated steel sheet; |
b) Rock Wool Sandwich Panels; |
c) EPS Sandwich Panels; |
d) Glass wool Sandwich Panels |
e) Skylight panel is used for day lighting |
f) Other materials as customers' request |
| Hot dip galvanized or anti-rust painted |
| Galvanized gutter and PVC downspout |
| Plastic steel or Aluminum Alloy |
| Sliding Door or hangar door |
| Welding connection or bolt connection |
| Flashing, ridge tile, screw and so on |
| 5MT, 10MT, 15MT and more |
| Standard seaworthy packaging or customized |
* In order to give you an exactly quotation and drawings, please let
us know your request length, width, eave height and local weather.
We will quote for you promptly. |
Sandwich Panel
Sandwich panel is suitable for prejects with high fireproof
requirement. With good sound-proof effect.In addition, noise indoor
caused by rain and hail are weakened obviously after sandwich used.
H-Shaped Steel
The advantages of our products: high-performance thermal
insulation, ventilation, moisture-proof materials provide extremely
high living comforts.
C-Shaped Steel
The advantages of this approach is durable life long, the production of high degree of industrialization, quality and stability. So heavily used by atmospheric corrosion is serious and difficult maintenance of outdoor steel structure
Roof and wall panel |
roof panel | 50/75/100mm sandwich panel (EPS, PU, Glass wool, Rock wool) or
color steel sheet |
Wall panel | 50/75/100mm sandwich panel (EPS, PU, Glass wool, Rock wool)or color
steel sheet |
rolling up door | auto-matic aluminum rolling up door/sandwich panel sliding door,
sandwich panel sectional door |
Single Wing door | sandwich panel door/aluminum hinged door |
Window | Aluminum/PVC sliding window with single glass/double glass |
Edge Cover | steel sheet (thickness 0.5mm) |
Fittings | glass adhesive, self-tapping screw etc. |
Other fittings & Accessories |
Embedded | M24 steel Q235, process |
Intensive bolt | Grade 10.9 |
Ordinary bolt | 4.8S |
Gutter | Color steel sheet, steel, stainless steel |
Water drain pipe | PVC |
Ventilator | Unpowered ventilator, electric monitor |
Stable Steel Frame
Steel frame structure consists of beams and columns from welded
H-shapede steel, hot rolled H-shaped steel. In this frames, the
beam and column system takes the gravity load such as dead and live
loads.
Our Company
QHHK offers virtually any type of structural design required. Your
building sqare footage, local cades and wind, rain, and seismic
requirements will determine the type of structural system that will
apply, Other considerations include interior space requirements
where clear spans may or may not be required. Standard bay length
are 6m, 7.5m, and 9m between main frames. A variety of endwalls
designs are available depending upon specific building demands.
Post and beam endwalls are standard optinal"rigid frame" endwall
designs are also available when there may be a need to add to the
building in the future or perhaps a need for a total opening such
as an aircraft hangar door. Our staff of experienced professionals
can be of great assistance in determining the right structure for
your application.
we make it easy to purchase a quality pre-engineered steel
building. QHHK's building specialists can assist in taking your
initial concept and developing the structural design with
accessories that best accommodates your needs.
One of many standard features offered on the majority of buildings
by QHHK includes the overlapping of purlins at the main beam as
opposed to the flush bolting method. this technique insures greater
strength and structural support. And as you will see, every aspect
of a QHHK steel building is designed to meet just the right
combination of quality and economy.
Success Case
------ Why Choose Us -------
1.Designing Ability
With help of modern designing softwares such as Auto CAD, PKPM,
3D3S, SAP2000, TSSD, Tekla Structures (Xsteel), 3DS MAX. We provide
full designing and detailing service to all customers.
2.Producing and Manufaturering by Ourselve.
We purchase the best quality raw material from An steel Co., Ltd.
We have 2 modern factories with a total area of 21000 square meters
to produce.
3. Visualization of the Production Process
We can provide you with picture information of all production links, from raw materials to steel processing, the whole
process of visual production.
4. Strict Quality Inspection
With good quality steel material, we have AWS-D1.1/D1.5 welding
quality system and professional CWI welding inspector to ensure
high quality of the product.
5. Packing and Delivery
Container and pallet packing will protect the surface paint or zinc
of the steel structures.
Delivery will be made 23 days after receipt of full payment.
Produce:
1. Production job based on steel building confirmed drawing.
2. We also can make the products use and drawing from customer.
3. Quality control work goes through every step during production.
4. Third Party Quality Check , customer on-site quality inspection
and any other reasonable inspection way is ok.
After-sale service:
1.After production, we will supply steel building installation
drawing
2.Send techinican to guide installation on site if customer
request.
Additional service:
if need us check the other factory, or need us inspect the
container loading , we are glad to help.
In order to supply the most suitable drawing and best price for
you, our design team need to confirm some information with you, as
below:
1 Location (where will it be built? ) _____country, city_____
2 Size: Length*width*height _____mm*_____mm*_____mm
3 Wind load (max. Wind speed) _____kn/m2, _____km/h, _____m/s
4 Snow load (max. Snow thickness)_____kn/m2, _____mm
5 Anti-earthquake grade_____
6 Brick wall needed or not. If yes, 1.2m high or 1.5m high?
7 Thermal insulation requirement. If yes, EPS/fiberglass wool/rock
wool/PU sandwich panels will be suggested; If not, the metal steel
sheets will be OK. The cost of the latter will be much lower than
the former.
8 Door quantity & size _____units, _____(width)mm*_____(height)mm
9 Window quantity & size _____units, _____(width)mm*_____(height)mm
10 Crane needed or not. If yes, _____units, max. Lifting
weight____tons; Max. Lifting height _____m
