Double Jacket Aerial 6 Core Outdoor ADSS Fiber Optic Cable

Double Jacket Aerial 6 Core Outdoor ADSS Fiber Optic Cable

Double Jacket Aerial ADSS Fiber Optic Cable

Cores available: 1-144 cores

Span: 50-1000 meters

Applications:

Aerial & conduit/duct application

CATV

Local trunk line

Computer networks system

Fiber Types

• G.651 multi-mode fiber
• G.652D single-mode fiber
• G.655 NZDS fiber for DWDM applications

Full range of protections

• Water Blocked

Optional protections

• Track resistant

  Dimensions of Cable Constructions

  Fiber count	Structure	Fibers per tube	Loose tube diameter (mm)	CSM diameter/pad diameter (mm)	Nominal Thickness of outer jacket (mm)	Cable diameter/ Height (mm)	Cable weight (kg/km)
  4	1+6	4	1.9±0.1	2.0/2.0	1.6	9.8±0.2	82
  6	1+6	6	2.0±0.1	2.0/2.0	1.6	9.8±0.2	82
  8	1+6	4	1.9±0.1	2.0/2.0	1.6	9.8±0.2	82
  12	1+6	6	2.1±0.1	2.0/2.0	1.6	9.8±0.2	82
  24	1+6	6	2.1±0.1	2.0/2.0	1.6	9.8±0.2	85
  36	1+6	12	2.2±0.1	2.0/2.0	1.6	10.0±0.2	85
  48	1+6	12	2.2±0.1	2.0/2.0	1.6	10.0±0.2	88
  72	1+6	12	2.2±0.1	2.0/2.0	1.6	10.5±0.3	98
  96	1+8	12	2.2±0.1	2.0/3.4	1.7	11.8±0.3	123
  144	1+12	12	2.2±0.1	3.0/7.2	1.7	15.2±0.3	175

FAQ:

1.What is your warranty time for ADSS aerial fiber cable ?

15 years' warranty for outdoor aerial optical fibre cables.

2. Do you have certificates for raw material?

ISO9001, ROHS,CE,FCC.

3. How long it takes shipping from China to South America countries ?

Usually 50 days by sea.

 Guangzhou jiqian fiber optic cable Co., Ltd (Guangzhou haiso fiber optic cable co.,ltd) is a fiber optic communication Manufacturer that started in 2011 is located at Guangzhou city ,and provides a professional fiber optic cable design and after-sales service for all over the world.

Our team full of spirituality and vitality, bloody and soulful!! For the cutsomer to the colleague must be the customer's service!!

All of our encounters are sincere links heart to heart!

Our advantage, with a history of over 10years, 5years export experience, ship to more than 30countries, more than 40 employees.

Choosing JQ is not only our success,but also yours!!!
