EN1092-1:2007 FLANGE
En1092-1 Flange Pn6 Pn10 Pn16 Pn25 Pn40 Type01 Type05 Type11 Type12
Forged Cs Ss
Type:TYPE01,TYPE02,TYPE05,TYPE11,TYPE12,TYPE13
Kind: WELD NECK /SLIP ON /PLATE /BLIND/LJ
Size: 1/2"-76"
Surface treatment:Yellow Paint, Anit Rust Oil,Hot Dip Galvanized,Cold Galvanized.
Material:S235JR,P245GH,P250GH ,P265GH,P280GH ,RST37.2,Q235
Material: 1.4404,1.4401,F304/304L,F316/316L
Certificate:ISO9001:2015,PED,TUV ,MILL TEST CERTIFICATE (EN 10204-3.1)
XINFENG was founded in 1988.
EN1092-1 FLANGE DETAIL:
| Typ 01: Plate (slip-on) flange for welding | Typ 13: Hubbed threaded flange |
| Typ 02: Loose plate flange with weld-on plate collar | Typ 21: Integral flange |
| Typ 04: Loose plate flange with weld-neck collar | Typ 32: Weld-on plate collars |
| Typ 05: Blank (blind) flange | Typ 33: Lapped pipe ends |
| Typ 11: Weld-neck flange | Typ 34: Weld-neck collars |
| Typ 12: Hubbed slip-on flange for welding | |
| FLANGES DIN / EN |
| Type | Norm | Nominal Pressure | Dimension |
| Welding Neck Flange | EN1092-1 Typ11 | PN6-PN400 | DN10-DN2000 |
| DIN 2631 - DIN 2638 |
| Blind Flanges | EN1092-1 Typ05 | PN6-PN400 | DN10-DN2000 |
| DIN 2527 |
| Flat Flanges for welding | DIN 2573 | PN6-PN40 | DN10-DN2000 |
| DIN 2576 |
| EN1092-1 Typ01 |
| Loose Flange + Weld-on Collars | DIN2642 | PN10-40 | DN10-DN2000 |
| EN1092-1 Typ02 |
| EN1092-1 Typ32 |
| Loose Flange + Weld Neck Collars | DIN 2673 | PN10-PN40 | DN15-DN2000 |
| EN1092-1 Typ04 |
| EN1092-1 Typ34 |
| Threaded Flanges | EN1092-1 TYP13 | PN10-PN40 | ½“-6“ |
COMPANY INTRODUCTION:
HEBHEI XINFENG HIGH-PRESSURE FLANGE AND PIPE FITTING CO., LTD (
XINFENG) was founded in 1988, specializing in the manufacture of
forged flanges and pipe fittings. Covering an area of 12000 square
meters, equipped with advanced production lines and inspection
instruments, Xinfeng now has become one of the biggest flange and
pipe manufactures in Hebei Pro., China, with an annual capacity of
8000 tons. Its main production equipment includes forging hammers,
ring-rolling machine, lathes, drillers, pushing machine, presses,
shot blasting machine etc. for the production of flanges, elbows,
tees, reducers and caps at different size range. Materials
available are carbon steel, stainless steel and alloy steel.
XINFENG has a group of rich-experienced engineers and technical
professionals, making it strong in technical force. Products are
manufactured in accordance with international standards such as
ANSI,DIN, EN1092, JIS, BS, GOST standards or with customers special
requirement and design. XINFENG has obtained ISO 9002 certificate
and follows in line with the system in the management and
production. Advanced production and inspection equipment, rich
experience and strict management systems well ensure its product
quality.
1. who are we?
We are based in Hebei, China, start from 1986,sell flange and pipe
fitting sold around the world.
2. how can we guarantee quality?
Always a pre-production sample before mass production;
Always final Inspection before shipment;
3.what can you buy from us?
Forged Flange, Fitting,Forged Fitting, Seamless Pipe.
4. what services can we provide?
Accepted Delivery Terms: FOB,CFR,CIF,EXW,FCA,DDP,DDU,Express
Delivery,DAF；
Accepted Payment Currency:USD,EUR,CNY;
Accepted Payment Type: T/T,L/C,D/P D/A,MoneyGram,Credit
Card,PayPal,Western Union,Cash,Escrow;
Language Spoken:English,Chinese,Arabic,French
