    50bpm Quad Seal Vertical Form Fill Seal Machine For Max Bag Width 250mm

    Ask Lasest Price
    Brand Name : ConFil Partner
    Model Number : CFP-SV500-C
    Certification : CE
    Price : USD9000 - 11000 per set
    Payment Terms : L/C, T/T, Western Union, MoneyGram
    Supply Ability : 60 sets per month
    Delivery Time : 10 - 25 working days
    • Product Details
    • Company Profile

    50bpm Quad Seal Vertical Form Fill Seal Machine For Max Bag Width 250mm

    Vertical Form Fill Seal Machine Quad Seal for Max Bag Width 250mm


    Vertical Form Fill Seal Machines are built by ConFil Partner, they have over 15 years experince in VFFS design, are familiar with Siemens Motion Control, trustful partner.

    CFP-SV500-C is intermittent motion VFFS, Config for Quad-seal package, with max. speed 50bpm.


    Specifications

    Model: CFP-SV500-C
    Max. speed: 50bpm
    Film systemFilm roll loading
    •Hand wheel
    •Max. film width 520mm
    •Max. outer diameter of film roll 360mm
    Film pulling
    •Servo control
    •Double belt pulling
    •Optical sensor for tracking mark
    Printing
    •Ribbon printer.
    Forming system
    •Forming tube change over without tool
    •Film position adjusted in HMI

    Package size

    (on pillow bag)

    •Width 80 ~ 230mm
    •Length 230 ~ 350mm
    Sealing systemVertical sealing
    •Single sealing bar made in copper
    Horizontal sealing
    •Sealing jaws made in copper
    •Pneumatic control
    •Cutting blade
    Safety system
    •Main power isolator
    •Operation key
    •Emergency stop button
    •Sensor on all doors
    •Movement stop and alarm in HMI
    compressed air supply0.4 m³/min, 6 bar
    Power supply220 Vac single phase, 50Hz, 4kW
    Machine frame materialStainless steel SUS304
    Machine weightApprox. 650Kg

    ConFil product range:

    • Multihead Weigher
    • Checkweigher

    We also provide ConFil Partner products:

    • Rotary Packer for pre-made pouch (sealing only, vacuum or MAP)
    • Vertical Form-Fill-Seal machine
    • Tray Denester
    • Metal detector

    Please contact us for the unique solution !
