80KM 1550nm SM XFP 10g Optical Transceiver
GX-H155-ZRC
10Gbps XFP Optical Transceiver, 80Km Reach
Features:
♦ XFP MSA Compliant
♦ Data rate from 9.95 Gbps to 11.1Gbps
♦ No Reference Clock required
♦ Cold Start up Wavelength Compliance
♦ EML transmitter and APD receiver
♦ Link length up to 80km
♦ Low Power Dissipation 3.5W Maximum
♦ -5ºC to 70ºC Operating Case Temperature
♦ Diagnostic Performance Monitoring of module temperature, supply
♦ Voltages, laser bias current, transmit optical power, receive
optical power
♦ RoHS compliant and lead free
Application:
♦ SONET OC-192&SDH STM 64
♦ 10G Ethernet
♦ 80 km 10G Fiber Channel
Description:
Gezhi's XFP Transceiver is designed for 10G SDH, 10G ZR and 10G
Fiber- Channel applications.
The transceiver consists of two sections: The transmitter section
incorporates a colded EML laser. And the receiver section consists
of a APD photodiode integrated with a TIA. All modules satisfy
class I laser safety requirements. XFP transceiver provides an
enhanced monitoring interface, which allows real-time access to
device operating parameters such as transceiver temperature, laser
bias current, transmitted optical power, received optical power and
transceiver supply voltage.
Ordering Information:
| Part Number | Product Description |
| GX-H155-ZRC | 1550nm, XFP, 10Gbps, 80km, 0ºC ~ +70ºC |
Company Information
GEZHI Photoncis is founded in 2011, which is a leading provider for optical active
and passive products in China. We design,develop,manufacture and
distribute the optical products to satisfy customer's need for
optical communication in Ethernet,SDH/SONET,Video monitor,FTTH,WDM
Netowrk, Access Network, CATV Network, EPON System etc.
Professional, delicated and passional, With reliable quality and
competitive pricing,,GEZHI Photonics supply over-expected products
and service to customers,In the past years, GEZHI have won the
confidence and great reputation from domestic and oversea
customers.
