RF Electronic Programmable Thermostat For Heating system 868MHZ radio frequency wireless room thermostat HVAC

Model :C7 RF

Transmitter: Receiver:

1. 2*AA size battery 1. AUTO/MANUAL Switch

2. 6 Time & 6 Temp,per day 2. LED system indicator

3. 7 Day programmable 3. Contact rating: 8(2)A 230VAC Max

4. 868Mhz for more stable communication

5. EL back light

6. Manual override mode

Description:

◆ Communicates at 868 MHz for stand-alone interface
◆ Transmits up to Beeline distance 660ft(200m)in the field (The distance will shorten if through walls and floors)
◆ 7days programmable, 6 events per day
◆ Backlit display (automatically turns off after 8 seconds of non-use)
◆ Fahrenheit / Centigrade
◆ 24Vac,110Vac,230Vac power supplied Controller
◆ Easy Installation

5+2 Day Programmable
◆ Override/Timing ON/OFF
◆ White Backlight (Optional)
◆ Infrared Remote Control (Optional)

Quick Detail:

220Vac

Surface mounting

7days 6 periods or 5+2 programmable

Description:

◆ Large LCD display
◆ 7days 6 periods or 5+2 programmable
◆ Error alarm
◆ low voltage alarm
◆ system setting mode selectable
◆ bule or orange backlight
◆ 12/24 hours clock selectable
◆ manual override

◆ batteries power supply
◆ Temperature accuracy selectable

Applications:

Our thermostat provides temperature control in industrial , commercial and residentcial application, especially for gas, oil, electric boiler and wall-hung boiler etc.
The Programmable Thermostat is designed for heating operation purpose with 7-Day, 6-periodes programming thermostat that provides universal system compatibility, precis comfort control to meet energy saving requirements.

Specifications:

◆ Temperature display range
◆ Temperature setting range
◆ Temperature accuracy
◆ Supply Voltage
◆ Sensor
◆ Wiring
◆ Enclosure
◆ Key
◆ Load voltage

0°C-37°C (32°F-99°F)
7°C-35°C (45°F-95°F)
± 0.5°C (± 1°F)
2 AA alkaline batteries
NTC 1% B=3950
terminal block
ABS
Silicone Rubber
AC220(5A)

Wireless Room Thermostat
Transmitter:
• 7 Day programmable
• 6 Time & 6 Temp,per day
• Green back light
• Manual override mode
• 868Mhz with more stable communication
• Wall mount or base mount
• °F/℃: Temperature display in °F/℃ format
• Battery power supply
Receiver:
• AUTO/MANUAL Switch
• LED system indicator
• Power supply: 230V AC
• Contact rating:6(2)A 250VAC Max

Ocean Controls Limited was founded by an industrial engineer with 15 years experience in the design and manufacturer of top-end electronic room thermostats.

We provide OEM/ODM services to worldwide customers, including manufacturing, designing,engineering and tooling.

With many years of experience, our products feature unrivalled quality, reliability and durability. We export our products all over the world, especially to European and American markets. Currently our main products includ: non-programmable/programmable thermostats,dial/push button/touchscreen thermostats, wired and wireless thermostats,we can also make timer,immersion/capillary thermostat and other related heating system control parts as per the customer’s request. The products meet CE, R&TTE,FCC,UL and CSA approved quality standards.

Our factory has three sets of SMT,10 sets of injection molding machine and advanced moulding equipments, Monthly capacity is more than 50,000 pcs, and this can be expanded according to customer requirement.

We have a strong R&D team with more than 15 years experience in the thermostat field, They are seasoned in the design,develop and testing of electronic thermostats, HVAC controller and accessories. In addition, we have broad experience in RF remote control products like remote wireless thermostats. Based on the above, we can design/develop new models for you upon your technical specifications or samples.

As a company, we strive to excel in the quality of products we sell, the service we provide and the support we give. We are committed to continuous improvement and on building win-win relationships with our partners.
