Shock-proof & Wear Resistant Axle-centre Alloy 40ХНЮ-ВИ，ЭП793 Russia 3J40 China Grade

Shock-proof & Wear Resistant Axle-centre Alloy 40ХНЮ-ВИ, ЭП793 Russia, 3J40 China Grade

Size range:

cold drawn wire: 0.2-6.0mm

Hot rolled/forged bar: 6-100mm

Shock-proof & Wear Resistant axle-centre alloy(YB/T5243-1993) Relative Grade:40ХНЮ-ВИ,ЭП793 Russia

Grade and Chemical Composition (see Table1) Table1 Grade and Chemical Composition Grade Chemical Composition (%) C P S Mn Si Fe Cr A1 Ce① Ni ≤ 3J40 0.03 0.010 0.010 0.10 0.20 0.50 39.0～41.0 3.30～3.50 0.10～0.2 Balance ①Based on addition Mechanical Property (see Table 2) Table 2 Mechanical Property Statue Vickers Hardness/ HV Commended Heat Treatment Bend Test The radius of the mandrel is twice as the diameter of the alloy I Ⅱ Ⅲ Cold Drawing 450～510 Bend 90 degrees. No cracks and broken on the outside of the bending Cold Drawn & Aging 780～830 >830～880 >880 480～540°C Keep warm for 5h Note: 1.The default hardness classification of the alloy wire in cold drawing & aging status is class II. Physical Property (see Table 3—Table 5) Table 3 Coefficient of Linear Expansion State Coefficient of Linear Expansion/(10-6/K) 20～55℃ 20～100℃ 20～200℃ 20～300℃ 20～400℃ 20～500℃ Solid Solution 12.2～12.7 12.4～12.5 12.6～12.8 13.0～13.1 13.5～13.6 13.8～14.0 Solid Solution&aging 11.0～11.5 11.9～12.0 12.0～12.2 12.4～12.5 12.7～12.8 13.1～13.3 Cold Drawn & aging 11.6 12.0 12.1 12.4 12.8 13.3 Table 4 Modulus of Elasticity & Frequency Temperature Coefficient State Modulus of Elasticity Temperature Coefficient βf/(10-6℃) Mechanical Quality Factor Q20℃ 20～-40℃ 20～100℃ Solid Solution +80% Strain Rate 176500～196000 Solid Solution +80% Strain Rate+Aging 5h 225500～235500 -103～-106 -104～-110 49000～51000 Table 5 Magnetic Susceptibility & Resistivity State Magnetic Susceptibility Resistivity/(μΩ•m) Density/(g/cm3) H=40KA/m H:80KA/m Solid Solution 3.5～4.5 3.5～4.6 7.6 Solid Solution+ Aging 3.8～4.0 2.4～4.2 Solid Solution+ Cold Drawing 2.8～3.0 1.21 Solid Solution +69% Strain Rate+Aging 0.78 Corrosion Resisting Property (See Table 5) Table 5 Corrosion Resisting Property State Salt Fog Test Long-time Store in The Air Cold Drawing+ Solid Solution+Aging No corrosion after 240 hours (Tested by the buyer per JB1606) No corrosion

Usage: It is applied to produce the axle-centre of instrument and meter as well as the axle-centre of the staff
