CISCO1941-SEC/K9 Original 1900 Series Integrated Security Bundle
network Router
Item's Status:
Stock
Type:
Wired
Application:
Enterprise
Function:
Firewall, QoS, VPN
LAN Ports:
Other
WAN Ports:
Other
Certification:
CE
Brand Name:
CISCO
Model Number:
CISCO3945E-SEC/K9
Place of Origin:
China (Mainland)
Feature:
Cisco Original
Item condition:
Brand New
Quality:
Cisco quality guarantee
Performance:
Excellent working condition
Warranty:
Two years
Lead Time:
Within 2-3 working days
Shipping:
DHL,FedEx,TNT,UPS,EMS,ARAMEX,Air Cargo
MOQ:
1 Piece
Payment Terms:
T/T or Western Union
Price:
Please contact us
Table 1 shows the Quick Specs.
| Product Code | CISCO3945E-SEC/K9 |
| Bundle | Cisco 3945E Security Bundle w/SEC license PAK |
| Services Performance Engine module | w/SPE 250 |
| Rack Units | 3U |
| Interfaces | 4 integrated 10/100/1000 Ethernet ports with 2 SFP ports |
| Expansion Slot(s) | 4 service module slots 3 Enhanced High-Speed WAN Interface Card slots 3 onboard digital signal processor (DSP) slots |
| RAM | 1 GB (installed) / 2 GB (max) |
| Flash Memory | 256 MB (installed) / 8 GB (max) |
| Dimensions | 13.3 x 43.8 x 47.6 cm |
CISCO3945E-SEC/K9 Security Bundle network Router:
| General |
|---|
| Device Type | Router |
| Enclosure Type | Desktop - modular - 3U |
| Connectivity Technology | Wired |
| Data Link Protocol | Ethernet, Fast Ethernet, Gigabit Ethernet |
| Capacity | Cisco Unified Communications Manager Express sessions : 450 ¦ Cisco
Unified SRST sessions : 1500 |
| Network / Transport Protocol | IPSec, PPPoE, L2TPv3 |
| Routing Protocol | OSPF, IS-IS, BGP, EIGRP, DVMRP, PIM-SM, IGMPv3, GRE, PIM-SSM,
static IPv4 routing, static IPv6 routing, policy-based routing
(PBR) |
| Remote Management Protocol | SNMP, RMON |
| Encryption Algorithm | SSL |
| Features | Firewall protection, VPN support, MPLS support, Syslog support,
content filtering, IPv6 support, Class-Based Weighted Fair Queuing
(CBWFQ), Weighted Random Early Detection (WRED), Access Control
List (ACL) support, Quality of Service (QoS), Dynamic Multipoint
VPN (DMVPN) |
| Compliant Standards | IEEE 802.3, IEEE 802.1Q, IEEE 802.1ah, IEEE 802.1ag |
| RAM | 1 GB (installed) / 2 GB (max) |
| Flash Memory | 256 MB (installed) / 8 GB (max) |
| Status Indicators | Link activity, power |
| Expansion / Connectivity |
|---|
| Interfaces | WAN : 4 x 10Base-T/100Base-TX/1000Base-T - RJ-45 ¦ Management : 1 x
console - RJ-45 ¦ Management : 1 x console - mini-USB Type B ¦
Serial : 1 x auxiliary - RJ-45 ¦ USB : 2 x 4 PIN USB Type A ¦ 2 x
SFP (mini-GBIC) |
| Expansion Slot(s) | 3 (total) / 3 (free) x EHWIC ¦ 3 (total) / 3 (free) x PVDM ¦ 2
(total) / 1 (free) x CompactFlash Card ¦ 4 (total) / 4 (free) x
service module (SM) |
| Power |
|---|
| Power Device | Power supply - internal |
| Voltage Required | AC 120/230 V ( 50/60 Hz ) |
| Miscellaneous |
|---|
| Width | 47.6 cm |
| Depth | 43.8 cm |
| Height | 13.3 cm |
| Weight | 17.7 kg |
| Compliant Standards | CISPR 22 Class A, CISPR 24, EN55024, EN55022 Class A, EN50082-1,
AS/NZS 60950-1, AS/NZ 3548 Class A, CAN/CSA-E60065-00, ICES-003
Class A, FCC CFR47 Part 15, EN300-386, UL 60950-1, IEC 60950-1, EN
60950-1, CSA C22.2 No. 60065, BSMI CNS 13438, NEBS |
| Software / System Requirements |
|---|
| OS Provided | Cisco IP Base Software |
| Manufacturer Warranty |
|---|
| Service & Support | 90 days warranty |
| Service & Support Details | Limited warranty - 90 days |
| Environmental Parameters |
|---|
| Min Operating Temperature | 0 °C |
| Max Operating Temperature | 40 °C |
| Humidity Range Operating | 5 - 85% |
One year warranty:
All of our Cisco products with one year manufacture warranty or
smartnet free for you buying smartnet at you local Cisco.
Faster Delivery and Rich export experience:
We can delivery your order all over the world by DHL, UPS, FedEx.
in 3-5days with Rich experience in export to avoid your worries.
Technology Supports:
Our Cisco engineer offering 24 * 7 mail professional supports.
Network designing and solutions for big ICT projects.
Consultancy, configuration, troubleshooting, etc for SMB.
Virieties of payment options:
We can accept the payment via "Wire ransfer", "Paypal", "West
Union". ect.
