Lithium Thionyl Chloride Cell , Custom Lithium Battery 1300mAh NB-IoT Meter and Sensor

    Buy cheap Lithium Thionyl Chloride Cell , Custom Lithium Battery 1300mAh NB-IoT Meter and Sensor from wholesalers

    Buy cheap Lithium Thionyl Chloride Cell , Custom Lithium Battery 1300mAh NB-IoT Meter and Sensor from wholesalers
    • Buy cheap Lithium Thionyl Chloride Cell , Custom Lithium Battery 1300mAh NB-IoT Meter and Sensor from wholesalers

    Lithium Thionyl Chloride Cell , Custom Lithium Battery 1300mAh NB-IoT Meter and Sensor

    Ask Lasest Price
    Brand Name : HCB
    Model Number : ER14335M
    Certification : UN/CE/UL
    Price : negotiable
    Payment Terms : T/T, L/C, MoneyGram, Western Union, D/A
    Supply Ability : two million unit per month
    Delivery Time : 5 working days
    • Product Details
    • Company Profile

    Lithium Thionyl Chloride Cell , Custom Lithium Battery 1300mAh NB-IoT Meter and Sensor

    ER14335M Lithium Thionyl Chloride Cell , Custom Lithium Battery 1300mAh


    Nominal Capacity1300mA
    Battery discharged at continuous current 2.7mA until voltage reaches cut-off voltage 2.0V at ambient temperature 23±2℃
    Nominal Voltage3.6 V
    Maximum Continuous Current210mA
    Battery with minimum 50% rated capacity discharged at ambient temperature 23±2℃
    Maximum Pulse Discharge Current420mA
    Battery with minimum 50% rated capacity discharged at max pulse for 3 seconds after 27seconds break. Ambient temperature 23±2℃
    Storage Condition

    Temperature ≤ 30℃

    Humidity ≤ 75%RH

    Operating Temperature-55℃ to +85℃
    Battery DimensionSee drawing on pag
    Max Weight13.0g
    Self-discharge Rate2%
    Max self-discharged rate at ambient temperature 23±2℃
    Shelf Life10 years
    Ambient temperature 23±2℃

    1. Battery Characteristic


    • High Voltage

    We offer the rated voltage of 3.6V, the working voltage varies with the load, generally between 3.3V ~ 3.6V

    • High Energy Density

    We offer the specific energy density of 360Wh/kg

    • Wide Operating Temperature Range

    We provide a wide operating temperature range, from -55℃ to +85℃

    • Stable Operating Voltage

    Stable operating voltage, more than 90% of the capacity could be output with a fixed voltage

    • Long Shelf Life

    The battery self-discharge less than 2% per year at room temperature


    Hermetic welding sealing to reduce the leakage for extending the shelf life to more than 10 years


    2. Main Applications


    • Security & alarms

    Smoke detectors, security alarms, seismometers, locking system, monitoring system, etc.

    • Electrical equipment

    Wireless electric power tools, computer RAM & COMS, UPS, CNC machine tools, (TPMS), camera, video camera, timer, calculator, electric toys, lighting equipment, etc.

    • Oil & gas

    Well pressure meters in high temperature, float meter, logging while drilling (LWD), measure while drilling (MWD), etc.


    3. Manufacturing Advantages


    • Advanced automatic technology is used in HCB;
    • The passivation is well controlled during the production;
    • We can produce high power, high capacity or low temperature batteries and so on;
    • The safety designs are multiple;
    • We have more than 20 years experience in the industrial technology of Li-SOCl2 batteries.

    4. Company Advantages


    • GB/T19001-2008/ISO9001:2008 is HCB quality management system standard;
    • Environment Management System of HCB is conformity with GB/T24001-2004/ISO14001:2004;
    • 1.2 meter drop test can be available to our battery;
    • Report for safe transport of goods can be provided with you if needed;
    • The CE certificate can be given to you if required;
    • The Rosh certificate can be given to you if required;
    • UL test is available for HCB Battery;

    5. FAQS of General Safety Instructions


    • In order to keep the battery safely, what should we do?

    Storage environment should be as dry as possible.


    • What kind of case do we need to stop using the battery?

    We need to stop using the battery when the abnormal heat release or leakage occurs.


    • What is the first step when you would like to use our battery?

    The manual should be read before the battery is used.


    • What is the effect of the signs + and - on the battery?

    You need to follow the signs + and - on the batteries and make sure not to reverse. If batteries are wrongly used, they will be hot very fast and can lead the gas and other toxic materials leakage.


    • What can't you do to the batteries?

    The batteries are able to be deformed or drilled into or damaged because the toxic materials or gas leakage may lead a big rupture.


    • Can the batteries be mixed to use on different electrochemical system, grades or brands?

    When changing batteries be aware that batteries of different electrochemical system, grades, or brands should be not mixed. If different batteries are used or in case of using old and new batteries together this can discharge batteries due to different voltage or capacity. This can cause toxic material or gas leakage and/or violent rupture.


    • Is it ok to put the batteries into the water?

    The water explosion will be caused if you throw the batteries into the water.
