Stable Producing Serpentine Spring Making Machine Automatic Oiling
| Modle | JD-212B Serpentine Spring Making Machine |
| Wire Diameter | 0.2mm-1.2mm |
| MAX Outer Diameter | 25mm |
| Max. Production Speed | 300pcs/min |
| Feed Length | Unlimited |
| Send The Spool(Y) | 0.85kw |
| The Camshaft(X) | 0.85kw |
| Monitor Display | Color/Chinese/English |
| The Machine Size | 80*65*145cm |
| Machine Weights | 500kg |
| Power | 220V 3P 50/60Hz |
| Packing | Wooden Case |
Description
Serpentine spring making machine
1. Wire Diameter range from 0.06 mm to 0.5 mm.
2. Max outer diameter up to 15 mm.
3. 2-axis control, for wire feed and pitch mechanism.
4. High precision equipped with CNC controlled servo-motion system
5. High production speed Max. up to 400 pcs/min..
6. Simplified setup and program with English/Chinese platform.
7. Capable of various kind of springs such as compression springs,
oil seal springs, taper springs, battery springs and so on.
Feeture
1. Wire feeding: Has four sets of feeding structure, increase the
stroke, so that it can product the spring those diameter up to
4.2mm, to adapt to a wider range.
2. Servo Motor: this part is refinedly made of aluminum alloy, max
speed is up to 3000 degrees per second (360 degrees in a circle as
calculated) thus the rotation angle of the spindle less work
without affecting the spindle speed. In addition to the core switch
can be rotated so that space to complete some complex shapes, it
can also be used to control the pitch of the spring, so the pitch
can be done to simplify the transfer of digital control machine
processes, thus reducing setup times.
3. Servo motors Angular: Angular is a digital servo means to
achieve freedom CORNER purposes. Computer-controlled bending angle
can be changed at any time, without the need to adjust the
mechanical parts, thereby reducing setup times, this bending
system, the maximum speed within 0.017 seconds of the wire into
90-degree corners, and folded into 180 degrees only need 0.034
seconds! Also knuckle device can swing 25 degrees, convenient
knuckle at certain angles inside.
Using spring machine produce out good springs need rich-experience and skilled workers,
however most of the users are lack of skilled workers, they can not
produce springs nice and fast.
Technical Support
Using cnc spring machiney produce out good springs need rich-experience and skilled workers,
however most of the users are lack of skilled workers, they can not
produce springs nice and fast.
Many factories do not provide after-sales service of machines in
oversea market because of many difficults, but we will not.
1. Instruction book is the most basic thing.
2. You can tell the specs of the springs to us, we will make a
video for you.
3. We have some HD camears for machines display, and these camears
are connecting with the Internet, we can show anything you want to
know under your requests through the Internet simultaneously.
4. Everytime you come to China, wellcome your visit and welcome to
study.
5. We can send engineers and translators to your country, the cost
need to share.
Spring Sample
Compare with other brand serpentine spring making machine
Our machine serpentine spring making machine committed to the pursuit of stability and precision, all mainly
accessories of the spring machine, such as wheel gear, motor,
bearing are all importing form Japan. Besides, we will do enough
producing processes to ensure the stability and pricision as well.
for example, we do steel pretreatment to prevent deformation, 12
steps of producing parts to ensure precision.
Make it more clearly with numbers, our machine can finsih
adjustment in half an hour before producing, and continue producing
for 1 hour without any adjustment more, other machines may need 1.5
or 2 hour to finish adjustment before producing, and check or
adjust the machine every 15 mins, because their machines are not
stable and precision enough.
Company Introduction
JINGDING Machine locaed in Dongguan, China.We are professional
manufacturing spring machine , spring coiling machine , spring
making machine , cnc spring machine , coil spring mhine achine ,
spring forming machine , torsion spring machine , compression
spring machine, coil spring machine, spring making machine used, second hand coil
spring machine, etc. JINGDING Has 10000 squire meters producing shop, can provide
60-80 sets machines every month. JINGDING committed to the pursuit
of producing "high stability " , "high precision " , " reasonable
price" machine for customers. The founder -Mr.Zou has been design,
develope and manufacture spring machine for 15 years, he really pay
attention to design and improve the quality of the machine with
acceptable cost. He is well versed in the principles of automation
,mechanical and electrical engineering, and make them in perfect
fit. After all these years improving of the machine, our spring
machines do have better performance than others.
JINGDING Machine with good quality, best technical suppot, and
reasonable price, looking for cooperate , and creaet better future
with you.
