    1-48 inch Stainless Steel Elbow 904L / A403 WP304 LR / SR R5 Bend

    Ask Lasest Price
    Brand Name : TOBO
    Model Number : Elbow
    Certification : SGS/BV/ABS/LR/TUV/DNV/BIS/API/PED
    Price : USD Depending on quantity
    Payment Terms : L/C, T/T, Western Union,
    Supply Ability : 3,0000pcs per month
    Delivery Time : 10-100 days depending on quantity
    • Product Details
    • Company Profile

    1-48 inch Stainless Steel Elbow 904L / A403 WP304 LR / SR R5 Bend

    Stainless Steel Elbow 904L / A403 WP304 Stainless steel elbow LR / SR R5 Bend.

    1.Stainless steel elbow
    2.sch5s-schxxs
    3.ISO9001,ISO9000
    4.Market:America,Africa,Middle East,Southeast of Asia
    product: stainless steel ansi b 16.9 a403 wp 904l elbow -BG BEST

    Products : Elbow bend equal ,/reduce tee,concentric/eccentric reducer , cap,flange
    Size: Seamless(SMLS) Elbows : 1/2"-24" ,DN15-DN600
    Butt Welded Elbows (seam) :24”-96",DN600-DN1800
    Type: LR 30,45,60,90,180 degree SR 30,45,60,90,180 degree
    1.0D, 1.5D, 2.0D, 2.5D, 3D,4D,5D,6D,7D-40D.
    Thickness: SCH10,SCH20,SCH30,STD SCH40, SCH60, XS, SCH80., SCH100, SCH120, SCH140, SCH160, XXS
    Standard: ASME,ANSI B16.9;

    MaterialASTM

    Carbon steel:ASTM A234WPB,,A234WPC,A420WPL6,A420WPL3
    MSS SP75 WPHY42/46/52/56/60/65/70

    Stainless steel:ASTM A403 WP304,304L,316,316L,321. 1Cr18Ni9Ti, 00Cr19Ni10,00Cr17Ni14Mo2, ect.
    Alloy Steel:A234WP12,A234WP11,A234WP22,A234WP5,A420WPL6,
    DINCarbon steel:St37.0,St35.8,St45.8
    Stainless steel:1.4301,1.4306,1.4401,1.4571
    Alloy steel:1.7335,1.7380,1.0488(1.0566)
    JISCarbon steel:PG370,PT410
    Stainless steel:SUS304,SUS304L,SUS316,SUS316L,SUS321
    Alloy steel:PA22,PA23,PA24,PA25,PL380
    GB

    10#,20#,20G,23g,20R,Q235,16Mn, 16MnR,1Cr5Mo,
    12CrMo, 12CrMoG, 12Cr1Mo

    Surface treatmentTransparent oil, rust-proof black oil or hot galvanized
    PackingIn wooded cases or pallets, or as for clients' requirements
    ApplicationsPetroleum, chemical, machinery, boiler,electric power, shipbuilding, papermaking, construction, etc
    CertificationAPI CE and ISO 9001:2008
    Third part inspectBV,SGS,etc accept
    Delivery time7 after receipt of advanced payment ,have stock ~
    special designas your drawing
    testDirect-reading Spectrograph,Hydrostatic testing machine,
    X-ray detector,Ultrasonic flaw detector,Magnetic particle
    detector,etc
    equipmentPress machine ,Bending machine,Pushing Machine,electric bevelling machine Sand-blasting machine,etc


    Description:

    1. Product Item No.: 001fittings-Cosco Steel

    2. Product name: 2205 Stainless Steel 90D LR Elbow

    3. Marking: Registered logo,Heat Number,Steel Grade,Standard,Size

    4. Packing: Wooden box or wooden pallet.

    5. H.S Code: 73072300

    6. Material: Stainless Steel: 304(CF8,1.4301),316 (CF8M,1.4408),2205 etc Alloy Steel: 12Cr1Mov, 10CrMo910, 15CrMo, A335, P22 etc.

    7. Standard:
    China Standard GB12459-90 etc
    U.S.A Standard ASTM A403,ANSI B16.9,ANSI B16.28,ANSI B16.11 etc
    Germany Standard KIN2605, DIN2606, DIN2615 etc
    Japanese Standard JIS B2311, JIS B2312, JIS B2313 etc.


    Applications:

    We,this type pipe fittings be widely used in kinds of industries:

    a. Paper Making,Waste-water Treatment

    b. Chemical Industry and Natural Gas

    c. Shipbuilding

    d. Electrical equipment

    e. Nuclear Energy

    f. Construction

    g. Petroleum


    Specification

    Nominal Pipe Size (NPS)Outside DiameterCenter-to-Center,OBack-to-Face,K
    mmInch
    1/221.30.847648
    3/426.71.057651
    133.41.327656
    11/442.21.669570
    11/248.31.9011483
    260.32.38152106
    21/273.02.88190132
    388.93.50229159
    31/2101.64.00267184
    4114.34.50305210
    5141.35.56381262
    6168.36.62457313
    8219.18.62610414
    10273.010.75762518
    12232.812.75914619
    14355.614.001067711
    16406.416.001219813
    18457.018.001372914
    20508.020.0015241016
    22555.922.0016761118
    24610.024.0018291219



    Our advantage

    i. Ultrasonic equipment for thickness inspection

    ii. Ultrasonic flaw detecting equipment

    iii. Universal material testing equipment

    iv. Carbon and sulfur analyzer
