Dongfeng Chasis LHD Electric Minibus Tourist Mini Bus 15 Passenger
Quick detail:
1. Model/ Type:MD6701(E)
2. Length × width × height(mm):6990×2040×2650
3. Wheelbase(mm):3935
Destription:
Mudan EV pure electric city bus E8 series is one of the new green
power for the Chinese market .It reduces the operating costs
because of environmental technology, high performance,
zero-emission, high efficiency, low noise, the achievements of a
high quality experience, cost performance,. Also it brings
environmental, pure for Chinese bus market.
Specifications:
| Vehicle model | MD6701(E) |
| Length × width × height(mm) | 6990×2040×2650 |
| Front / rear overhang(mm) | 1150/1905 |
| Wheelbase(mm) | 3935 |
| G.V.W(kg) | 6500 |
| Front / rear axle load(kg) | 2700/4300 |
| Rated passenger(person) | 23-29 |
| Maximum speed(km/h) | 80 |
| Rear axle | Dana axle,4.3T, |
| Drum brakes(Main Reducer:3.7) |
| Suspension Systems | Small leaf spring(3/4),Hydraulic shock absorber,Front stabilizer
bar |
| Braking Systems | Brake pipeline | Pneumatic double-loop |
| Parking brake | Energy storage spring air break |
| Steering System | Power steering, Right |
| Tank | 50L |
| Electrical systems | Electrical lines | 24V,single system,minus earth |
| Battery and battery box | with a 12V battery |
| Body structure | Semi-bearing type,Light duty framework +Stamping skin |
| Rear emergency exit | with emergency exit and accessory |
| Lighting | Integral headlight,Integral taillight |
| Line cards | Front LED line card,Specially designed for the Hong Kong market |
| Exterior Rearview Mirrors | rod type,Specially designed for the Hong Kong market |
| windscreen wiper | wiper with a same direction(right) |
| Side windows | upper the sliding side windows,Under the seal |
| passenger door | Manual folding door |
| Interior | Molding interior top |
| (with A/C airduct ) |
| Dashboard | RHD,Luxury dashboard,Decorated with mahogany,Debris box |
| A/C | overhead air conditioning(Export version) |
| Driver seat | High back, adjustable front and rear,Height adjustable, adjustable
backrest |
| Passenger seat | 2+1 type,Ordinary seat,cann't be traversed |
| Floor | Bamboo floor with high-density(12mm) |
| Paint | PPG Prime paint |
Product Advantages:
1. Famous cooperative partner: Dongfeng,JMC,JAC
2. Compared with similar products, the bus has a higher safety
index
3. Most competitive price
4. Energy saving and Environmental friendly
Packing and shipping:
Packing: Nude
Shipping: Ro-ro transportation
