ASME B16.47 Series B Class 600 Weld Neck Flanges ASTM A182 Size:
1/2" - 60"
Brand Name: | TOBO |
Model Number: | ASTM A182 |
Certification: | SGS/BV/ABS/LR/TUV/DNV/BIS/API/PED |
Place of Origin: | China |
Product Name | Copper-Nickel Flange | Product Type | WN FLANGE |
Size | 1/2" - 60" | Class | 600 LBS |
Facing | As per drawing | Type | Weld Neck Flange, WN Flange (Raised Face) |
Standard | ANSI/ASME: | finish | Cool rolled |
Application | Water Heater |
Minimum Order Quantity: | 1pcs |
Price: | Depending on quantity |
Payment Terms: | T/T or Western Union or LC |
Supply Ability: | 3,0000pcs per month |
Delivery Time: | 10-100 days depending on quantity |
Packaging Details: | PLY-WOODEN CASE OR PALLET |
ASME B16.47 Series B Class 600 Weld Neck Flanges Size: 1/2" - 60"
Specification:
Size: 1/2" - 60"
Brand Name: TOBO
Class: 600 LBS
Type: Weld Neck Flange, WN Flange (Raised Face)
Specialize: As per drawing
Standard:
ANSI/ASME:
ANSI B16.5, ANSI B16.47, MSS SP44, ANSI B16.36, ANSI B16.48
DIN:
DIN2527, DIN2566, DIN2573, DIN2576, DIN2641, DIN2642, DIN2655,
DIN2656, DIN2627, DIN2628, DIN2629, DIN 2631, DIN2632, DIN2633,
DIN2634, DIN2635, DIN2636, DIN2637, DIN2638, DIN2673
B.S:
BS4504, BS4504, BS1560, BS10, etc
Weld Neck Flanges are drilled with the wall thickness of the Flange
having equal dimensions to the matching pipe. The lighter the pipe
is the larger the bore is in the Weld Neck Flange. And conversely
the heavier the pipe is the smaller the bore is in the Weld Neck
Flange. Weld Neck Flanges are usually used in high pressure systems
and are suitable for cold or hot temperatures.
ASME B16.47 Series B Weld Neck Flanges
ASME B16.47 Series B Class 75 Weld Neck Flanges
ASME B16.47 Series B Class 150 Weld Neck Flanges
ASME B16.47 Series B Class 300 Weld Neck Flanges
ASME B16.47 Series B Class 600 Weld Neck Flanges
ASME B16.47 Series B Class 900 Weld Neck Flanges
Weld Neck Flanges Material & Grades:
Stainless Steel Weld Neck Flanges: ASTM A182, A240 F 304, 304L, 304H, 316, 316L, 316Ti, 310, 310S,
321, 321H, 317, 347, 347H, 904L
Carbon Steel Weld Neck Flanges: ASTM / ASME A/SA 105 ASTM / ASME A 350 , ASTM A 181 LF 2 / A516
Gr.70 A36, A694 F42, F46, F52, F60, F65, F70
Alloy Steel Weld Neck Flanges: ASTM / ASME A/SA 182 & A 387 F1, F5, F9, F11, F12, F22, F91
Duplex Steel Weld Neck Flanges: ASTM / ASME A/SA 182 F 44, F 45, F51, F 53, F 55, F 60, F 61
Super Duplex Weld Neck Flanges: ASTM / ASME A/SA 182, A240 F 44, F 45, F51, F 53, F 55, F 60, F 61
Nickel Alloy Weld Neck Flanges: Nickel 200 (UNS No. N02200), Nickel 201 (UNS No. N02201), Monel
400 (UNS No. N04400), Monel 500 (UNS No. N05500), Inconel 800 (UNS
No. N08800), Inconel 825 (UNS No. N08825), Inconel 600 (UNS No.
N06600), Inconel 625 (UNS No. N06625), Inconel 601 (UNS No.
N06601), Hastelloy C 276 (UNS No. N10276), Alloy 20 (UNS No.
N08020), etc
Copper Alloy Weld Neck Flanges: UNS No. C10100, 10200, 10300, 10800, 12000, 12200, 70600, 71500,
UNS No. C 70600 (Cu -Ni- 90/10), C 71500 (Cu-Ni-70/30)
Low Temperature Carbon Steel Weld Neck Flanges: ASTM A350, LF2, LF3
Applications Of ASME B16.47 Series B Class 600 Weld Neck Flanges
ASME B16.47 Series B Class 600 Weld Neck Flanges are used in
Chemical and petrochemical processing.
ASME B16.47 Series B Class 600 Weld Neck Flanges are used in
electronics.
ASME B16.47 Series B Class 600 Weld Neck Flanges are used in
processing equipment for maintaining product purity in handling
foods, synthetic fibers.
ASME B16.47 Series B Class 600 Weld Neck Flanges are used in marine
and offshore engineering.
Characteristics of ASME B16.47 Series B Class 600 Weld Neck Flanges
ASME B16.47 Series B Class 600 Weld Neck Flanges are highly
resistant to various reducing chemicals.
ASME B16.47 Series B Class 600 Weld Neck Flanges are excellent
resistance to caustic alkalies.
ASME B16.47 Series B Class 600 Weld Neck Flanges are high
electrical conductivity.
ASME B16.47 Series B Class 600 Weld Neck Flanges are excellent
corrosion resistance to distilled and natural waters.
ASME B16.47 Series B Class 600 Weld Neck Flanges are resistance to
neutral and alkaline salt solutions.
ASME B16.47 Series B Class 600 Weld Neck Flanges are excellent
resistance to dry fluorine.
ASME B16.47 Series B Class 600 Weld Neck Flanges are widely used to
handle caustic soda.
ASME B16.47 Series B Class 600 Weld Neck Flanges are good thermal,
electrical and magnetostrictive properties.
ASME B16.47 Series B Class 600 Weld Neck Flanges offer some
resistance to hydrochloric and sulfuric acids at modest
temperatures and concentrations.
Dimensions of ASME B16.47 Series B Class 600 Weld Neck Flanges
Pipe Normal Diam. | O.D.
OF
Flange | Thick
ness
(Thk.) | Length
Through
Hub | Diam. of
Hub
at Base | Hub
Diam.
Top | Raised
Face
Diam. | Diam. of
Bolt
Circle | No. of
Bolt
Holes | Diam. of
Bolt
Holes | Diam. of
Bolt | Fillet
Radius
Min. |
inch | O | C | Y | X | A | R | BD | BN | BH | DB | r1 |
26" | 889 | 111.3 | 180.8 | 698.5 | 660.4 | 726.9 | 806.5 | 28 | 44.5 | 1 5/8 | 12.7 |
28" | 952.5 | 115.8 | 190.5 | 752.3 | 711.2 | 784.4 | 863.6 | 28 | 47.8 | 1 3/4 | 12.7 |
30" | 1022.4 | 125.5 | 204.7 | 806.5 | 762 | 841.2 | 927.1 | 28 | 50.8 | 1 7/8 | 12.7 |
32" | 1085.9 | 130 | 215.9 | 860.6 | 812.8 | 895.4 | 984.3 | 28 | 53.8 | 2 | 12.7 |
34" | 1162.1 | 141.2 | 233.4 | 914.4 | 863.6 | 952.5 | 1054.1 | 24 | 60.5 | 2 1/4 | 14.2 |
36" | 1212.9 | 146.3 | 242.8 | 968.2 | 914.4 | 1009.7 | 1104.9 | 28 | 60.5 | 2 1/4 | 14.2 |
38" | Size 38" through 60" are identical to series a, Class 600 flanges. |
|
