    Steel Wire Armored Low Smoke Zero Halogen Cable

    Ask Lasest Price
    Brand Name : SHANCABLE
    Model Number : WDZAN-YJY33
    Certification : PCCC/ISO/CE/KEMA
    Price : USD 0.5-60/meter
    Supply Ability : 500km per month
    Delivery Time : As per requirement
    • Product Details
    • Company Profile

    Steel Wire Armored Low Smoke Zero Halogen Cable

    Steel Wire Armored Low Smoke Zero Halogen FRC Cable for Hospital School and

    Skyscraper


    Application


    lszh cable is suitable for cable channel, laying in indoors,and conduit etc., such cables can’t bear

    strong mechanical force.XLPE Insulation has excellent chemical corrosion resistance, but also

    has the properties of flame retardant and non water absorption.


    Conductor Shape



    Parameter


    1. Long-time working temperature should be lower than 90°C, should not be lower than 0°C.

    2. Once short-circuit (the Max. duration 5s), the maximum conductor temperature does not be

    over 160 °C

    3. Fire-resistant, Flame retardant, LOSH, Can Do As Your Request.


    Production Range of Low Voltage Cable
    TypeConstructionsNumber of coresRated Voltage kV
    0.6/1(1.2)1.8/3
    1.9/3.3
    Nominal cross-section of conductor mm2
    1, Cu/PVC/PVC
    2, Cu/XLPE/PVC
    3, Cu/XLPE/LSZH
    4, Al/PVC/PVC
    5, Al/XLPE/PVC
    6, Al/XLPE/LSZH
    Conductor: Copper or Aluminum
    Insulation: PVC or XLPE
    Over sheath: PVC, PE or LSZH
    Remark: The cable can be of flame retardant,
    fire resistance, environment friendly or other property.
    11.5-80010-800
    21.5-50010-500
    31.5-50010-500
    4 (3C+E)1.5-50010-500
    5 (4C+E)1.5-50010-500
    1, Cu/PVC/PVC/STA/PVC
    2, Cu/XLPE/PVC/STA/PVC
    3, Cu/XLPE/LSZH/STA/LSZH
    4, Al/PVC/PVC/STA/PVC
    5, Al/XLPE/PVC/STA/PVC
    6, Al/XLPE/LSZH/STA/LSZH
    Conductor: Copper or Aluminum
    Insulation: XLPE or PVC
    Inner sheath: PVC, PE or LSZH
    Armor: Steel tape or Aluminum tape
    Over sheath: PVC, PE or LSZH
    Remark: The cable can be of flame retardant,
    fire resistance, environment friendly or other property.
    11.5-80010-800
    21.5-50010-500
    31.5-50010-500
    4 (3C+E)1.5-50010-500
    5 (4C+E)1.5-50010-500
    1, Cu/PVC/PVC/SWA/PVC
    2, Cu/XLPE/PVC/SWA/PVC
    3, Cu/XLPE/LSZH/SWA/LSZH
    4, Al/PVC/PVC/SWA/PVC
    5, Al/XLPE/PVC/SWA/PVC
    6, Al/XLPE/LSZH/SWA/LSZH
    Conductor: Copper or Aluminum
    Insulation: XLPE or PVC
    Inner sheath: PVC, PE or LSZH
    Armor: Steel Wire or Aluminum wire
    Over sheath: PVC, PE or LSZH
    Remark: The cable can be of flame retardant,
    fire resistance, environment friendly or other property.
    11.5-80010-800
    21.5-50010-500
    31.5-50010-500
    4 (3C+E)1.5-50010-500
    5 (4C+E)1.5-500
