0.018mmCu + 0.023mmPET x 390mm Laminated Copper Foil for Cable
Structure
1. Copper technical data
| Thickness | Density | Hardness | Conductivity | Elongation | Tensile Strength |
| mm | g/cm3 | HV | %IACS | 10(%) | Mpa |
| 0.018 | 8.9 | 63.12 | >=90 | 26 | 160 |
2.Chemical compositions
| Cu+Ag | Fe | Bi | Sb | As | Sn | Ni | Zn | O | Pb | S |
| >=99.99 | =<0.005 | =<0.001 | =<0.002 | =<0.002 | =<0.002 | =<0.005 | =<0.005 | =<0.06 | =<0.005 | =<0.005 |
| Remarks: O=<0.06, Impurlty: =<0.1 |
3. Product Status
| M(soft) | Y2(1/2Y) | Y(hard) | T(extra hard) |
| Product Standard | Refer: GB/T2059-2008. GB/T5231-2001 |
4. Our advantage
1. Since 1988, we have rich experience in this industry in China;
2. Good reputation in copper cable industry;
3. We have our own development department for new material
research;
4. Good experience and cooperation with big client in the world;
5. With Certificate ISO9001-2008;
6. High performance cost ratio;
7. Fast delivery time;
8. Good communication skills, and good service and understandings
for customers;.
5. Application
Radio-shielding application of cables, wrapping and shielding
application of cable. Cable foil is used as a skin for
heat-insulating and electromagnetic shielding to provide high
performance for Cable industry
6. Features
1. Insulation shield for cable; It can be used for protecting the
high frequency transmission of telecommunication cable; power cable
and electric wire from the interference of electromagnetic and
radio wave;
2. Copper foil are widely used for coaxial cable shield and
electronic product like EHV cables and RF cables; shielding layer
of many other kinds cables;telephone lines and ventilation ducts,
etc;
3. Electromagnetic interference shielding;isolate electromagnetic
waves to prevent damage to the human
4. Good insulativity and shielding effectiveness to reduce
attenuation;avoid the voltage or current influence function;
5. Good thermal insulation; waterproof; cold resistance;Easy to
peel; stick force resistance;
7. FAQ:
1, Q: Are you manufacturer?
A: Yes, we are established in 2003. As a manufacturer our customers
are welcome to visit our factory.
2, Q: Do you accept customized orders?
A: Yes, we do. Your customized orders are always welcomed. Please
kindly offer us your technical perfrmances or samples so that we
can customize the products according to your preferences. About any
further detail, please feel free to contact us.
3. Q: How can I get one quotation faster?
A: Pls offer details about your demands as more as
possible,insulation thickness,over diameter,nominal voltage,working
temperature,color,quantity,application,etc.
4. Q: If I can not offer above information,what should I do?
A: Try your best to offer more information,we will help you design
suitable wires&cables.
5. Q: What is your company sample policy?
A: As one supplier,we see that sample is necessary for our both
sides,our policy is to offer free sample as possible as we can,just
one situation is exception,sample is with very complex
structure,besides,we have no it in stock.
About sample shippment,you need to pay for the freight,usually
freight collect by express.
