    Automatic Shredded plastic machine/Waste wood shredder manufacturer price

    Ask Lasest Price
    Brand Name : STPLAS Plastic Shredder Machine
    Model Number : ST800 Plastic Shredder Machine
    Certification : CE
    Price : 9,600-128,000USD/SET
    Payment Terms : T/T
    Supply Ability : 30sets/month
    Delivery Time : 30-60days
    • Product Details
    • Company Profile

    Automatic Shredded plastic machine/Waste wood shredder manufacturer price

    Brief introduction.

    Plastic Shredder Machine is mainly used in shredding materials that are quite thick and tough such as large plastic pipes and lumps, shredder used close packed structures with hydraulic feeding system.it's featured as advanced equipment ,strong crushing capacity and high output.

    Working principle.

    The main shaft keeps running at high speed, and there are many fixed robust knifes on it which can tear up the plastic blocks easily when the cart which is driven by the hydraulic system pushes the blocks froward. This shredder is really high efficient and vigorous. An invincible warrior to destory any form plastic material.

    Main features:

    1. Plastic Shredder Machine is mainly used to crush big size plastic products ,such as headpiece material, thick-walled large diameter plastic pipe, film roller, paper, fibreand others.
    2. The rotary blade seat and blade can be disassembled.which makes it easier to clean and maintain.
    3. The rotary bladeadopts V shape installation so that the blades can cut material evenly, It can decrease the noise and energy consumption.
    4. Each rotary blade has 4 same cutting knife edge, when one side becomes dull, you can change another side into using. which prolongs the service time of rotaty blades.
    5. The main shaft is driven by gearbox, which supplies steady running and powerful speed.
    6. The material keeps being pushed foward by the hydraulic system, which ensures the raw material can be crushed thoroughly and efficiently.
    7. PLC program control system, automatically rotating,shut down, safe and reliable running of the machine. The blade can rotate in opposite direction.

    Specification


    ModelST1-600ST1-800ST1-1000ST1-1200
    Push Power(kw)1.52.22.25.5
    Mainmotor power
    (kw)
    18.5373755
    Rotary blade28384858
    Stationary blade2244
    Shaft diameter(mm)220400400400
    Rotate speed(r/min)908580

    75



    ROTOR: Various rotor configurations available for processing a wide range of materials. Blades are made from hardened DC53 steel, the blades can be turned 4 times before changing.GEARBOX: Water cooled gearbox guards against overloading. Hardened teeth on the reducer.
    CE CERTIFIED: Safety devices in line with European CE CertificationSHOCK ABSORBE: Absorbs vibrations caused by the shredding of the material. This protects the machine and its various parts from damage.

    RAM: The hydraulic ram pushes material against the roto
    BEARING SEAT: Protective bearing covers to avoid foreign contamination entering the bearing housing. Grease points to release oil at intervals to increase
    SCREEN: Various screen sizes.HYDRAULIC STATION: The ram pressure and timing can be adjusted to suit different materials. From WT40 series and above the machine can be fitted with wind cooled two-speed pump.
    Technical Features:
    1. The shredder single shaft for plastic with big feeding mouth, it can put the big plastic or rubber product freely.
    2. The rotary and cutting blade with edge of special design, it can get very high efficiency and high capacity.
    3. The shredder single shaft for plastic is control by PLC system; the blade can rotate inopposite direction and close automatically if something unexpected happens; with very high safety service.
    4. The shredder single shaft for plastic runs slowly with low noise and less dusty.
    5. The blade material with special alloy steel made, with long life.
    6. All the machinery and electrical devices are protected in accordance with the European CE standard.
    7. Hydraulic system Pushes the material automatically to the shredding rotor while working. More efficient and can achieve a high capacity. According to material kind, can adjust the pushing speed to avoid overload.
    8. Cooler system(optional) can maintain the temperature for continuous operation.
