6P - 25P Air Energy Heat Pump , School Central Air Conditioning System

Name: 6P 25P Air Energy Heat Pump School Central Air Conditioning System
Brand: Yushen
Price: 1 USD

Add to Cart

6P ~25P Air Energy Heat Pump Central Air Conditioning System for School / University / College

Brief Introduction

Appplication: Big models for school buildings' bath, hot water, air conditioning of office buildings, central heating of residential area
Project overview:Central heating stations of 10 dormitory buildings and 11 teaching buildings, over 170000 square meters of school
Advantages:
Clean---compared with coal boilder, gas boilder , air source heat pump only use electricity,it is envrionmental friendly
Energy saving---for large project, in one heating season (120 days), the power bill is only USD0.08/kwh/M2
Space saving---air source heat pump could be installed on the top of buildings, the system is easy and flexiable.
Safety---In the system is 50C hot water in winter and 7C cool water in summer, water and electrical parts are seperated, air conditioning is more comfortable and safe.

Model data/ Parameter of central AC ASHP

A7W35 working condition: inlet air temperature 7℃, outlet water temperature 35℃

a: Nominal heating conditions: ambient dry bulb temperature-12℃, wet bulb temperature-14℃, outlet water temperature 41℃, water flow 0.172 * nominal

Model				SLNA-017Y	SLNA-032Y	SLNB-035Y	SLNB-047Y	SLNC-075Y
Compressor capacity				6HP	10HP	12.5HP	15HP	25HP
Function				Heating and Cooling	Heating and Cooling	Heating and Cooling	Heating and Cooling	Heating and Cooling
Electricity				380V-3N-50Hz	380V-3N-50Hz	380V-3N-50Hz	380V-3N-50Hz	380V-3N-50Hz
Working conditions			℃	-25~～+45	-25~+45	-25~+45	-25~+45	-25~+45
Data	Heat^a	Nominal capacity	KW	12	21.5	22.3	28.1	44.5
		Input power	KW	4.55	9.1	9.4	11.7	18.3
		COP	/	2.4	2.3	2.35	2.4	2.4
	Heating IPLV(H)			2.7	2.7	2.7	2.7	2.7
	Cool^b	Nominal capacity	KW	14	25	28	39	62
		Input power	KW	5	10	10.4	13.1	20.7
		COP	/	2.5	2.5	2.7	2.9	3
	Cooling IPLV(C)			2.7	2.7	2.7	2.7	2.7
	A7W35c		KW/COP	19.5/4.21	32.0/4.1	35.0/4.1	47.0/4.1	75.0/4.2
	A2W35		KW/COP	27/3.60	27/3.60	28.5/3.60	39.5/3.20	62.5/3.20
	A-7W35		KW/COP	21.5/2.8	21.5/2.8	23.5/2.9	32/2.9	50/2.9
	A-15W55		KW/COP	19.7 /1.94	19.7 /1.94	20.2 /1.94	28.1/1.94	45.5 /1.97
	A-20W45		KW/COP	18.1/2.02	18.1/2.02	18.7/2.02	23.6/2.03	37.4/2.04
Max. running currency			A	25	25	27	35	56
Compressor quantity			set	2	2	1	2	2
Refrigerant/charging quantity kg			/	R22/4.8	R22/3.7*2	R22/9	R22/10	R22/15*2
Air blow type			/	Side	Top	Side	Top	Top
Water pipe diameter			mm	G1.2〞	32	32	50	50
Rating flow			m³/h	3.2	5.5	5.9	8.3	12.6
Water side pressure loss			kPa	≤45	≤45	≤45	≤45	≤45
Noise level			dB(A)	62	62	62	62	62
Overall dimensions(L×W×H)			mm	1120×440×1360	1530×750×1370	1490×900×1900	1450×1100×2080	2100×1100×2080
Weight			kg	130	320	350	470	730

Yushen Products Advantages

Larger application range , yushen heat pump could be used from environmental temperature:-25℃ to +45 ℃ /or from -13℉ to 113 ℉
100% finished products testing,quality Components such as Copeland compressor, Danfoss valves
35% more powerful than other products,yushen air-source heat pump has longer heating time and shorter defrosting time
High COP, No capacity decay even under low environmental temperature
