    Transmission Submerged Drag Chain Conveyor Submerged Ash Conveyor Quick Load

    Ask Lasest Price
    Brand Name : YONGXING
    Model Number : chain belt type,screw type,ball type,heavy industrial use
    Certification : ISO9001,ISO14001
    Price : negotiable
    Payment Terms : T/T, L/C, Western Union
    Supply Ability : 1000SETS/YEAR
    Delivery Time : 10-15days
    • Product Details
    • Company Profile

    Transmission Submerged Drag Chain Conveyor Submerged Ash Conveyor Quick Load

    Industrial casting iron SGB type scraper slag remover and dust cleaner for coal fired boiler


    scraper slag remover Features:


    1. Spiral slag removal machine can be used with horizontal quick-load coal-fired boilers to keep the boiler room clean and tidy, reduce gas pollution and reduce the labor intensity of the furnace workers. At the same time, the boiler can be burned under negative pressure, which further improves the thermal efficiency of the boiler.


    2. The dusty ash should control the moisture content in the ash hopper. At the same time, it is forbidden to contain iron blocks, hard objects and unburned wood blocks into the cylinder to avoid jamming the screw shaft or damaging the mechanical device.


    3. The transmission structure of the spiral slag removing machine is a worm gear, and the motor and the coupling are connected by rubber soft plates in the middle, which can effectively reduce vibration and mechanical wear. The first-stage shifting gear is a cylindrical helical gear, and the large gear drives the worm gear to function as a shifting gear. The worm gear is directly connected to the spiral main shaft to serve as a conveyor.


    scraper slag remover main technical parameters:

    The diameter of the screw shaft is often: 200~300mm

    Motor speed: 30~75r/min

    Conveying material type: granules or crumbs.

    Applicable boiler: boiler with rated evaporation of less than 25t/h.

    Mounting angle: <40°


    Boiler removal screw type
    CZX TYPE (Length <8M Slag 0.6-2.3T/H)
    For boiler 6ton/h~25ton/h

    Techniacal Prameters of CZX Type Seris Spiral Slag Machine
    TypeMathching
    Boiler
    Cylinder length(mm)Cylinder inside
    diameter*thickness
    Power
    (kW)
    Slag bucket size (mm)Dimensions
    (mm)
    CZX-3.11-4T/H3103Φ400*790L-6-1.1kW1650*6303710*900*1800
    CZX-3.7-3.85-6T/H3703-3803Φ400*790L-6-1.1kW1742*8304313*1000*2000
    CZX-46-8T/H4003Φ400*7100L-6-1.5kW2430*9304613*1200*2000
    CZX-4.28-10T/H4203Φ400*7100L-6-1.5kW2430*9304913*1300*2000
    CZX-4.310T/H4303Φ400*7100L-6-1.5kW2430*1804913*1300*2000
    CZX-4.510T/H4503Φ400*7100L-6-1.5kW2530*11805113*1300*2000
    CZX-4.615T/H4603Φ400*7100L-6-1.5kW2530*11805213*1300*2300
    CZX-4.915T/H4903Φ400*7100L-6-1.5kW2730*11805513*1300*2500
    CZX-5.220T/H5203Φ400*8100L-6-1.5kW2930*11805813*1300*3000
