    High Pressure Gas Fired Steam Boiler Fully Automatic Flexible Water Tube Boiler

    Ask Lasest Price
    Brand Name : YONGXING
    Model Number : SZS10-30-1.25/1.6-YQ
    Certification : ISO9001,ISO14001,A-CLASS,SGS,BV
    Price : negotiable
    Payment Terms : T/T,L/C,Western Union
    Supply Ability : 1000SETS/MONTH
    Delivery Time : 15-30DAYS
    • Product Details
    • Company Profile

    High Pressure Gas Fired Steam Boiler Fully Automatic Flexible Water Tube Boiler

    Best serviceable SZS series high pressure gas fired water tube boiler with fully automatic


    Installation instructions of SZS oil-gas-steam boiler -- electric control operation cabinet
    The control switch buttons of burner and feed pump are concentrated on the electronic control control cabinet. Users can first pull the wires to each motor and then connect the external power supply.
    Note: the casing shall be protective grounded.


    The electric control control cabinet shall be installed in a special operation room or in front of the boiler. The installation orientation shall be conducive to the monitoring of various instruments on the boiler and ensure convenient operation.


    SZS oil-gas steam boiler -- installation of pipes, valves, instruments and accessories
    1. Before installation should check the instrument, do a good job of valve test.


    2. When installing pipelines, valves and instruments, install them according to the boiler room design drawing, fix the electric pump in an appropriate position, and test run after power supply is switched on.


    3. The safety valve should be installed after the hydraulic test, the safety valve should be connected with the discharge pipe, the discharge pipe should be directly to the safe place, and there is enough cross-section and anti-freeze measures to ensure the smooth discharge.


    4. Connect the blowdown pipe to the blowdown box or other safe places, and fix the pipe to prevent shifting or scalding during blowdown.


    5. Steam pipelines outside the main steam valve shall be connected by the user. There shall be at least one elbow on the main steam valve pipeline; otherwise, expansion pipe shall be installed.


    6. When the device pressure gauge, should make the dial surface vertical, the pressure gauge dial should draw a red line to show the boiler maximum allowable working pressure, pressure gauge cock rotation flexible, no steam leakage, drainage should be smooth, the pressure gauge pipe is prohibited from heat insulation.


    7. The manufacturer only provides part of the installation parts, and other direct pipe users need to prepare by themselves, and make corresponding connections according to the installation drawing.


    Typical SZS series steam boiler technical parameter list
    modelSZS10-1.6-QYSZS15-1.6-QYSZS20-1.6-QYSZS25-1.6-QYSZS35-1.6-QYSZS45-1.6-QY
    Rated evaporation t/h101520253545
    Rated steam pressure MPa1.6
    Rated steam temperature °C204
    Feed water temperature °C105
    Boiler design thermal efficiency%93.5%~100.6%
    Common fuelNatural gas / light diesel
    Combustion methodForced ventilation, micro-positive pressure combustion
    Exhaust gas temperature °C55~150
    Fuel consumption (natural gas) Nm3/h70310551406175824613164
    Gas supply pressure (natural gas) mbar20~3030~5030~5030~505050~200
    Maximum transport weight t273237425135
    Maximum transport size m6.7x3.2x3.57.2x3.4x3.47.7x3.6x3.98.5x3.8x4.19.6x4.1x4.310.0x3.5x3.8
    Mainframe dimensions (including platform, energy saver)9.0x5.6x4.49.9x5.6x4.010.5x5.7x4.611.3x6.0x4.812.4x6.6x5.013.0x6.8x5.2
    Description:
    1. The boiler is mainly designed with natural gas and light diesel oil. It is also suitable for city gas, liquefied petroleum gas, biogas, coke oven gas and mine gas.
    2. The fuel consumption is calculated based on the calorific value of natural gas 36006KJ/Nm3 and the calorific value of light oil 42705KJ/kg.
    3. We follow the principle of continuous improvement and improvement of product performance. The data of the new generation products may be changed. The data in the table is for reference only.
