MOV-01, MOV-02, MOV-03, MOV-03A Sunrise 3/2 way MOV Series
Mechanical Valves
The MOV series stands out for its diversity of actuator options and
robust construction, making it suitable for direct human or machine
interaction. Key models like the MOV-01 (selector button), MOV-02
(roller lever), and MOV-03 (locking button) provide flexibility for
different operational needs, all while sharing common port sizes
like G1/8". These valves act as fundamental input components in pneumatic
control systems, prized for their simple structure, stable
performance, and long service life. They are engineered for precise
direction control, often processed by CNC machines, and are
applicable in a wide range of fields from factory automation to
agricultural irrigation systems due to their large flow capacity
and high working frequency.
Order Codes:
| Item Code | Port Size | Positions | Button Type |
|---|
| MOV-01 | 1/8" | 3/2 way | Selective Knob |
| MOV-02 | 1/8" | 3/2 way | Roller Type |
| MOV-03 | 1/8" | 3/2 way | With Lock Button |
| MOV-03A | 1/8" | 3/2 way | Plat Round Button |
Specifications:
| Model | MOV-01 | MOV-02 | MOV-03 | MOV-03A |
|---|
| Working Medium | 40 Micron Filtered Air |
| Position and Way NO. | Two-position Three-way |
| Joint Pipe Bore | G1/8" |
| Working-pressure Range | 0~0.8MPa |
| Operating Temperature | 0~70℃ |
Dimensions:
Quality Standards:
The company for the products are brand new original products, no
second-hand and refurbished products, or leave a compensable ten
and return the full amount , but the buyer due to our purchase of
model error is not responsible for returns, another of the
company's sales of products enjoy one year from the date of
shipment quality assurance , according to the original quality
standards , during warranty with product problems , need
confirmation testing by the manufacturer , the supplier to be
solved , the demand side due to storage , use, poor maintenance
caused by lower-quality product , and not raise objections.
Samples:
You can send a sample to customize the products, we have many
engineers can help it; If you want a product of mine, but you are
not sure if it's what you want, so you can ask for a sample from
me, it will be free.
After-sale service:
We can provide a series of after-sale service, such as product
introduction, mounting, debugging, technical support and so on.
Competitive Advantage:
| Our product features: | Our Services Guarantee: |
| 1) Competitive price | 1) Prompt respond (Reply with 24 hours) |
| 2) Good quality | 2) Free Samples (Customer pay for the delivery cost) |
| 3) Professional Packaging | 3) 1 year warranty |
| 4) Produce according to Customers’ instruction | 4) Photos/videos are available during production. |
| 5) None delay shipment | 5) Loading inspection, and send loading photos before shipment. |
