Pneumaitc Metal Push In Fittings Nickel Plated Brass Male Stud Swivel Elbow

Nickel Plated Brass Male Stud Swivel Elbow Metal Pneumatic Push-In Fittings
Features

1. Connection and disconnection of the tube can be repeated several times and is performed with one hand, without using of tools. 2. Nickel-plated brass bodies ensure anti-corrosion and anti-contamination. 3. The sealing ring(O-ring) can be easily replaced if it is damaged. 4. Most all models available in inch and metric size. Material Body and collet:Nickel-plated Brass O-ring:NBR(other material is available on request) Threads BSPT,BSPP,NPT,Metric threads Pressure Tube to connect 0.8-16bar(see tube) PU,PE,Nylon 6-11-12 Fluid Compressed air Temperature -10℃-60℃(see data of used tubing) Products code system 1:Model type 2:Tube outer dia METRIC SIZE INCH SIZE Code 04 05 06 08 10 12 14 16 1/8 5/32 3/16 1/4 5/16 3/8 1/2 Dia. 4mm 5mm 6mm 8mm 10mm 12mm 14mm 16mm 1/8inch 5/32inch 3/16inch 1/4inch 5/16inch 3/8inch 1/2inch 3:Thread Size METRIC SIZE Code M3 M5 M6 M8 M10 M12 M12A M14 M16 M20 Dia. M3×0.5 M5×0.8 M6×1 M8×1 M10×1 M12×1.25 M12×1.5 M14×1.5 M16×1.5 M20×1.5 55°Taper Pipe Thread(BSPT) G-Thread(BSPP) Code 01 02 03 04 06 08 G01 G02 G03 G04 Dia. R1/8 R1/4 R3/8 R1/2 R3/4 R1 G1/8 G1/4 G3/8 G1/2 American Standard Taper Pipe Thread (NPT) Code U10 N00 N01 N02 N03 N04 N06 N08 Dia. 10-32UNF NPT1/16 NPT1/8 NPT1/4 NPT3/8 NPT1/2 NPT3/4 NPT1

CIxi Qianyi Pneumatic & Hydraulic Co.,ltd(QPE) is specialized in manufacturing metal push in fittings and other brass pneumatic fittings,pneumatic and hydraulic couplings.We are manufacturing fittings with both lnch and metric measurement system. And our factory established in 1996,now our factory become one of the largest manufacturers of pneumatic & hydraulic fittings in China.

We have a technical team with skilled workers who are able to the whole course of R&D,Quality Controls,Production,Designing.And we can manufacturing any special pneumatic & hydraulic fittings upon customers,request.And we also can supply OEM.And we have passed ISO9001 standard.

Our factory follows competitive price and good quality,has been exported many countries.Such as United States,UK,Germany,Holland,Italy,Turkey,South Africa and South East etc.we are looking forward to enjoying prosperity with friends all over the world.

Ordering from QPE is very easy. Give us a telephone,fax or email,you will get more details.We will serve you with our pleasure and will try our best to meet your varieties of demands.

Our delivery will be safe and prompt. Act immediately!
