    Vertical 8 Inch Borehole Submersible Pumps 12-465m Head High Performance

    Ask Lasest Price
    Brand Name : APK
    Model Number : QJ
    Certification : ISO;CE,BV; TUV; CCC
    Price : Negotiable
    Payment Terms : T/T, Western Union
    Supply Ability : 9863 sets per month
    Delivery Time : Within 2-5 working days upon receipt of payment
    • Product Details
    • Company Profile

    Vertical 8 Inch Borehole Submersible Pumps 12-465m Head High Performance

    Head 12-465m 7.5kw 22kw 30kw 37kw 45kw 8 Inch Water Submersible Borehole Pumps


    A very competitive reputable OEM&ODM submersible pump manufacturer.

    We manufacturing from raw material cast to finished production to package.


    Submersible borehole pumps applications:

    1. Residential and commercial building services: circulation in heating and cooling systems, domestic hot water, water supply
    2. Desalination, offshore,jack-up, floating dock,shipyard
    3. Public utilities: water supply and district heating solutions
    4. Agriculture: irrigation systems solutions
    5. Aquaculture: water transport solutions
    6. Mining: water supply and dewatering solutions

    Working conditions of submersible borehole pumps:

    1. Three-phase power supply, voltage 380V (error less than 5%), frequency 50Hz (error less than 1%).

    2. Motor must be filled with clean water.

    3. The primary impeller of the pump should be immersed at least 2m under dynamic water level. The pump unit shall be less than 70m deep under static water level. The foot of motor shall be at least 3m above well bottom.

    4. Water temperatureshould not higher than 20 ℃.

    5. Sand content of the water (by quality) not more than 0.01%.

    6. Water PH 6.5~8.5.

    7. The content of hydrogen sulfide in watershould not be more than 1.5 mg/l.

    8. The content of chloridion in water shouldnot be higher than 400mg/l.

    9. The water source must provide enough water for the pump to work continuously.

    8 inch submersible borehole pumps parameters:

    (It is regular submersible pump type in Shenlong pump factory, stainless steel 304/316/316l/duplex stainless/ss904L and 380v/440v/480v/600v/660v, etc. Please kindly choose submersible pump type you are interested.)


    DiameterModelMotor PowerFlow rangeMeter range
    Inch (")QJ Series(kw)hpm3/hm
    8"200QJ15-81/67.51013-1768-92
    8"200QJ20-189/14223018-22160-217
    8"200QJ20-230/17253518-22195-265
    8"200QJ20-338/25375018-22287-388
    8"200QJ20-351/26456018-22298-403
    8"200QJ25-154/1118.52523-27138-184
    8"200QJ25-168/12223023-27140-195
    8"200QJ25-308/22375023-27260-355
    8"200QJ32-176/11304029-35148-203
    8"200QJ32-182/14304029-35154-210
    8"200QJ32-234/18375029-35199-270
    8"200QJ32-273/21456029-35232-313
    8"200QJ40-104/818.52537-4389-124
    8"200QJ40-117/9223037-4394-140
    8"200QJ40-130/10253537-43114-155
    8"200QJ40-169/13304037-43144-201
    8"200QJ40-182/14375037-43154-214
    8"200QJ40-195/15375037-43166-232
    8"200QJ40-234/18456037-43206-277
    8"200QJ50-45/3101446-5436-54
    8"200QJ50-52/4131846-5442-62
    8"200QJ50-104/8253546-5484-124
    8"200QJ50-135/9304046-54119-162
    8"200QJ50-143/11375046-54121-165
    8"200QJ50-169/13375046-54143-195
    8"200QJ50-195/13456046-54165-225
    8"200QJ50-195/15456046-54165-225
    8"200QJ63-28/27.51058-6824-33
    8"200QJ63-84/6253558-6872-96
    8"200QJ63-98/7304058-6884-114
    8"200QJ63-112/8304058-6893-131
    8"200QJ63-126/9375058-68100-147
    8"200QJ63-140/10456058-68120-164
    8"200QJ63-154/11456058-68130-180
    8"200QJ80-33/3131874-8628-37
    8"200QJ80-44/4152074-8637-50

    Customer Case:

    200QJ flow 63m3/h, head 80m, 4 sets, 22kw clean water supply for running water

    1. Flow: 63m3/h

    2. Head: 80m

    3. Pump Power: 22kw
    4. Application: Pumping clean water
