    Electric Driven Clamshell Split Frame Machine , Pipe Cold Cutting Tools

    Ask Lasest Price
    Brand Name : Wellnit
    Model Number : OCE-159
    Certification : CE
    Price : Negotiable
    Payment Terms : T/T, L/C
    Supply Ability : 50 sets month
    Delivery Time : 5-7 days
    • Product Details
    • Company Profile

    Electric Driven Clamshell Split Frame Machine , Pipe Cold Cutting Tools

    Electric Driven Clamshell Split Frame Machine , Pipe Cold Cutting Tools


    The series machine is ideal for all types of pipe cutting, beveling and end preparation.


    The split frame design allows the machine to split in half at the frame and mount around


    the OD of the in-line pipe or fittings for strong, stable clamping.


    The equipment performs precision in-line cut or simultaneous cut/bevel, single point, counterbore and


    flange facing operations, as well as weld end preparation on open ended pipe, Ranging from 3/4” to 56


    inches O.D.(DN20-1400), on most wall thicknesses and material.


    ModelWorking Range (ID-OD)Wall ThicknessRotation SpeedAir pressureAir Consumption
    OCP-89Φ25-893/4''-3''≤3550r/min0.6MPa1500 L/min
    OCP-159Φ50-1592''-5''≤3521r/min0.6MPa1500 L/min
    OCP-168Φ50-1682''-6''≤3521r/min0.6MPa1500 L/min
    OCP-230Φ80-2303''-8''≤3520r/min0.6MPa1500 L/min
    OCP-275Φ125-2755''-10''≤3520r/min0.6MPa1500 L/min
    OCP-305Φ150-3056''-10''≤3518r/min0.6MPa1500 L/min
    OCP-325Φ168-3256''-12''≤3516r/min0.6MPa1500 L/min
    OCP-377Φ219-3778''-14''≤3513r/min0.6MPa1500 L/min
    OCP-426Φ273-42610''-16''≤3512r/min0.7MPa1800 L/min
    OCP-457Φ300-45712''-18''≤3512r/min0.7MPa1800 L/min
    OCP-508Φ355-50814''-20''≤3512r/min0.7MPa1800 L/min
    OCP-560Φ400-50616''-22''≤3512r/min0.7MPa1800 L/min
    OCP-610Φ457-61018''-24''≤3511r/min0.7MPa1800 L/min
    OCP-630Φ480-63020''-24''≤3511r/min0.7MPa1800 L/min
    OCP-660Φ508-66020''-26''≤3511r/min0.7MPa1800 L/min
    OCP-715Φ560-71522''-28''≤3511r/min0.7MPa1800 L/min
    OCP-762Φ600-76224''-30''≤3511r/min0.8MPa2000 L/min
    OCP-830Φ660-81326''-32''≤3510r/min0.8MPa2000 L/min
    OCP-914Φ762-91430''-36''≤3510r/min0.8MPa2000 L/min
    OCP-1066Φ914-106636''-42''≤359r/min0.8MPa2000 L/min
    OCP-1230Φ1066-123042''-48''≤358r/min0.8MPa2000 L/min

    Main Features:


    1. Lower axial and radial clearance.

    2. Cold cutting and beveling,No spark.

    3. Easy set-up &Robust operation.

    4. Process carbon steel ,stainless steel ,alloy etc with U,V,J compound bevel.

    5. Widely used in the fields of petroleum,chemical,natural gas,food ,boiler,medicine,


    power supply construction and nuclear power.


    It is widely used in long-distance transport pipeline, power plant, nuclear power, petroleum,


    chemical engineering, natural gas, boiler shop, pharmacy, pipe prefabrication plant, pipeline


    installation engineering, rush-repair work, etc.


    MachinePipe cutting and beveling machine1PC
    Drive ModePneumatic Motor1PC
    ComponentsAluminum alloy/wooden packing case1PC
    Cutter holder1PC
    Cutting blade1PC
    ToolsRubber hammer, Spray bottle, Square, Wrench set1SET
    DocumentsOperating manual, SFM1PC
    Certificate of conformity, SFM1PC
    U-disk1PC

    Modelworking range(ID-OD)wall thicknessrotation speed
    OCE-159

    Φ50-159(2”-5”)

    ≤30mm

    21r/min
